  Doxygen – Source Code Documentation Generator Tool Albert Guo [email_address]
• 2.
  Agenda What isDoxygen Doxygen Features Getting Start Check the result
• 3.
  What is DoxygenDoxygen is source code documentation generator tool Doxygen is a documentation system for C++, C, Java, Objective-C, Python, IDL (Corba and Microsoft flavors), Fortran, VHDL, PHP, C#, and to some extent D. Official Site: http://www.stack.nl/~dimitri/doxygen/index.html You can go to here, http://www.stack.nl/~dimitri/doxygen/manual.html , to get further information
• 4.
  Doxygen Features Canextract the code structure from undocumented source files. Shows relations between the various elements (functions, typedefs, structs, etc.) as hyperlinks Can generate inheritance diagrams and other diagrams
• 5.
  Getting Start
• 6.
  Getting Start –cont. Click Wizard button
• 7.
  Getting Start –cont. Assign Project Name Assign your source repository, and check the scan recursively checkbox Assign the document generation destination
• 8.
  Getting Start –cont. Scan all entities Select your language
• 9.
  Getting Start –cont. Select your output format
• 10.
  Getting Start –cont. Assign the diagram you want to generate
• 11.
  Getting Start –cont. Save doxygen config file
• 12.
  Getting Start –cont. Assign Doxygen working directory
• 13.
  Getting Start –cont. Click Start to start document generation
• 14.
  Getting Start –cont. Generation finished
• 15.
  Check the resultClass hierarchy UML Diagram
• 16.
  Check the result– cont.
• 17.
  Check the result– cont.
• 18.
  Check the result– cont.
