Object-Oriented Design: Multiple inheritance (C++ and C#)
The document discusses object-oriented design concepts, particularly focusing on inheritance and composition, along with their implications for software reuse and maintainability. It outlines various design types, including concrete, abstract, wrapper, delegate, and handle classes, as well as principles like interface segregation and dependency inversion. The text also examines challenges such as multiple inheritance and offers insights on managing complexity and promoting effective design strategies.
More Related Content
Similar to Object-Oriented Design: Multiple inheritance (C++ and C#)
Object-Oriented Design: Multiple inheritance (C++ and C#)
- 1. Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved Object-‐Oriented Design Inheritance vs. ComposiAon: Part II Inheritance for Interface: Multiple Inheritance
- 2. Design QuesAons • How to implement mulAple inheritance? • What type is most important? – DisAnguish between potenAal base classes – Decide which type(s) to subordinate Copyright@2015 Adair Dingle
- 3. Key ObservaAons • Inheritance and composiAon BOTH provide reuse • Interface inheritance is not true inheritance – but can serve to fulfill client needs • Design impacts soSware maintainability Copyright@2015 Adair Dingle
- 4. Chapter 8: Design AlternaAves & PerspecAves ComparaAve Design Design types and alterna/ves for client use • Class design types • Design for Inheritance • Inheritance vs. ComposiAon • MulAple Inheritance • Design Principles Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 5. Why consider SoSware Design? • Design impacts soSware use – Efficiency, OpAmizaAon (Inlining), Maintainability, … – Ease of subtype manipulaAon, heterogeneous collecAons, ... – Interface adaptaAon, type subordinaAon, … • Design impacts soSware reuse – Type extensibility – Type checking, type extracAon • Class designers should carefully consider design alternaAves • Different costs and benefits – Inheritance vs composiAon – Exposed/echoed/wrapped interfaces – Type definiAon/idenAficaAon/extracAon Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 6. Class Design Types • Concrete – immediately usable – Simple, efficient, standalone type – Inheritance NOT intended • Abstract – not instanAable – Defines common interface for class hierarchy – Inheritance REQUIRED • Node -‐-‐ Intermediate class in class hierarchy – Inherits interface – provides resoluAon or refined behavior – Inheritance anAcipated Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 7. Class Design Types -‐-‐ conAnued • Wrapper – Isolates client from instable or proprietary interface – May echo porAon of wrapped interface – May augment/coalesce/modified wrapped behavior – Wrapped object replaceable without impact • Delegate – Wrapped subObject – Replaceable, possibly polymorphic – ResponsibiliAes delegated to wrapped subObject • Handle – Transparent resource manager – Tracks wrapped subObject – No alteraAon in wrapped behavior Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 8. Encapsulated SubObjects • Wrappers encapsulate exisAng types – reusing (and possibly augmenAng or modifying) funcAonality – frequently isolate applicaAon programmer from unstable interfaces – wrapped subObject may be replaced without any impact – subObject’s interface, if echoed, oSen echoed in a modified fashion. • Delegate is (wrapped) subObject – provides key funcAonality to the wrapper class – may be exchanged, replaced, stubbed out, and/or polymorphic. • Handle promotes transparency – provides external access to internal funcAonality of wrapped subObject – e.g. smart pointer – Unlike wrappers, handles do not augment or modify subObject funcAonality. Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 9. Abstract Classes • Define interface for class hierarchy – Determine funcAonality accessible via heterogeneous collecAon • May or may not provide default behavior • Require inheritance • EffecAve design with polymorphism – May dilute cohesion if designed but unnecessary Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 10. Abstract Classes • A class is DESIGNED as abstract when • At least one method is undefined • only protected constructors provided => Client cannot instanAate instance of class • C#/Java provide keyword abstract • code more readable and thus maintainable • C++ does not provide keyword abstract • UAlity of abstract classes remains the same – regardless of syntacAcal differences across languages Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 11. Example 8.4 Abstract Classes //C++: no keyword abstract C#/Java: just use keyword abstract // C++ => at least one method must be pure virtual class Toy { public: virtual bool safe() = 0; … }; //Abstract BY DESIGN (C++, C#, Java,…) // => protected constructor, no public constructor class Vehicle { protected: Vehicle(); public: … }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 12. Example 8.5 Delegate Use class seminarAttendee // delegate could be object or pointer { // indirection supports postponed instantiation idVerifier delegate; … void replaceDelegate(…) { idVerifier newImproved(…); delegate = newImproved; } public: … // pass requests to delegate bool registerD() { return delegate.isSet() } bool isValid() { return delegate.verify(); } bool renew() { if (!registerD() || !isValid()) return false; return (delegate.getAge() > 18) } }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 13. Example 8.6 Polymorpic Delegate class HasADelegate { idVerifier delegate; BaseType* polyD; void replaceDelegate() { delete polyD; if (…) polyD = new MinType(…); else if (…) polyD = new MaxType(…); else if (…) polyD = new MeanType(…); } public: // simple echo int getAge() [ return delegate.getAge(); } // additional layer of indirection supports polymorphism void dynamicProcess() { return polyD->process(); } … }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 14. Table 8.4 Inheritance Effects Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved Motivation Characteristics Benefits Costs Code reuse Inheritance of Implementation Reuse existing class May suppress/NOP interface Reduce : --development time --cut & paste design --maintenance Code complexity Increased coupling Decreased cohesion Unavoidable overhead Fixed cardinality Dependency on parent Lifetime association Type extension Inheritance of Interface Is-a relationship Subtype relevant Type familiarity Substitutability Polymorphism Heterogeneity Extensibility
- 15. Inheritance vs. ComposiAon Both support Code Reuse Inheritance supports type extensibility polymorphism heterogeneous collecAons Inheritance provides built-‐in and efficient mechanism for type-‐checking promotes design clarity and maintainability Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 16. Inheritance vs. ComposiAon ComposiAon affords the class designer more control • subObject may be manipulated in ways that a parent cannot • InstanAaAon may be postponed • subObjects may be replaced • Cardinality, lifeAme, associaAon and ownership may vary – All fixed design for inheritance • Interfaces may be selecAvely echoed • Overhead can be avoided • Unstable types may be wrapped Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 17. Example 8.8 Inheritance vs ComposiAon class B { protected: virtual void filter(); public: … virtual void store(); }; class QueenInheritB: public B { public: // keyword used for documentation // once virtual always virtual!! virtual void store() { B::store(); filter(); … } … }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 18. Example 8.8 conAnued class QueenComposeB { B subObject; public: // cannot access protected B::filter() // virtual nature of B::store() not relevant void store() { subObject.store(); … } … }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 19. Example 8.9 ComposiAon with Exposed Interface class Be: public B { public: … // make inherited protected method public void filter() { B::filter(); } }; class QueenComposeB2 { Be subObject; public: // can filter by using intermediary class void store() { subObject.store(); subObject.filter(); } }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 20. Example 8.10 Inheritance vs Polymorphic Subobjects class flexQueen { B* subObjP; public: // constructor can instantiate any B (sub)type object // subObjP = 0 or subObjP = new Be or subObjP = Bee … flexQueen() { subObjP = new B; … // other choices } virtual void store() { subObjP->store(); // dynamic behavior } void replaceB(B*& worker) { delete subObjP; subObjP = worker; worker = 0; } … }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 21. MulAple Inheritance • Like single inheritance, mulAple inheritance – promotes type extensibility – supports polymorphism. • MulAple inheritance increases design complexity – two divergent ancestral paths needed to understand class – Two-‐degree variance may compromise maintainability • Two classic design difficulAes – AMBUGUITY: parental interfaces overlap – REDUNDANCY: common grandparent component Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 22. MulAple Inheritance • Ambiguity easily resolved – Two parents define same funcAon signature => COMPILER ERROR – Child class must override doubly inherited funcAon • redefine or direct call to specific parent => Descendant class definiAons compile • Redundancy NOT easily resolved – Two parents share same ancestor – Child class inherits two copies of common ancestor – Duplicate copy cannot be suppressed easily Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 23. Example 8.12 Resolving Ambiguity: C++ MulAple Inheritance class StudentEmployee: public Employee, public Student { … public: … int getAge() { return Student::getAge(); } int getSeniority() { return Employee::getAge(); } }; Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 24. Type SubordinaAon • Inheritance simulated via ComposiAon – One (or both) parent is defined as a subObject – Necessary when mulAple inheritance NOT supported (C#/Java) • Class designer selects subObject & thus subordinates a type • subObject does not have visibility of a parent component – its interface is not assumed – Its interface must be echoed if needed • No is-‐a relaAonship to support type interchange in client code – Design changes not ‘automaAcally’ passed with compilaAon – No external subsAtutability for subObject – No heterogeneous collecAons typed to subObject Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 25. Type SubordinaAon EffecAve design technique • Permits simulaAon of inheritance • adds flexibility and control over – InstanAaAon – Cardinality – AssociaAon – LifeAme – Ownership – Interface Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 26. Example 8.17 C# StudentEmployee: Student parent interface EmployeeI { … } public class StudentEmployee3: Student, EmployeeI { // contain zero or more Employee components private Employee e; // interface forces echo of Employee functionality … } // why ‘Employee’ subordinated to ‘Student’? Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 27. Table 8.5 Simulate MulAple Inheritance using ComposiAon Motivation Benefits Costs No provision for multiple inheritance in implementation language Clear subordinate parent type Efficiency Type depends on one parent for utility not interface Variable cardinality Replaceable subobject Insulating layer Shield from parent Polymorphic subobject Inconvenient loss of: -- Protected interface Design constrained by loss of: --Type familiarity --Substitutability --Polymorphism --Heterogeneity --Extensibility Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 28. Interface SegregaAon Principle Interfaces should be small and contain only a few, related methods • Exalts interfaces as key design component • Promotes high cohesion and low coupling • Confines breadth of interface – Narrow interfaces focus design and imply specific uAlity. – Wide interfaces undermine cohesion and maintainability • Targets interacAng class design – whether for inheritance or composiAon. Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 29. Program to Interface Not to ImplementaAon Model func/onality, decoupled from implementa/on, by using abstract classes and interfaces. => Implementa/on can then vary independently. • Exalts interfaces as key design component • Upholds OOD abstracAon and encapsulaAon – Isolate client from volaAle/arbitrary implementaAon • Drives complementary class design – whether for inheritance or composiAon. Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
- 30. Dependency Inversion Principle High-‐level abstrac/ons are more stable. If dependencies exist, preferable that low-‐level abstrac/ons depend on high-‐level abstrac/ons • reinforces value of an extensible, possibly abstract, interface at the base of a class hierarchy. • suggests choice when determining subordinate class – Client should be isolated from the least abstract type. – if any lower-‐level details change, client code is shielded. Copyright@2014 Taylor & Francis Adair Dingle All Rights Reserved
