• 1.
  PACKAGES Explained By: Sarbjit Kaur. Lecturer,Department of Computer Application, PGG.C.G., Sector: 42, Chandigarh
• 2.
  Packages • Packages areJava’s way of grouping a number of related classes and/or interfaces together into a single unit. That means, packages act as “containers” for classes. • The benefits of organising classes into packages are: - The classes contained in the packages of other programs/applications can be reused. - In packages classes can be unique compared with classes in other packages. That two classes in two different packages can have the same name. If there is a naming clash, then classes can be accessed with their fully qualified name. - Classes in packages can be hidden if we don’t want other packages to access them. - Packages also provide a way for separating “design” from coding.
• 3.
  Java Foundation Packages Javaprovides a large number of classes groped into different packages based on their functionality • The six foundation Java packages are: - java.lang : Contains classes for primitive types, strings, math functions, threads, and exception. - java.util : Contains classes such as vectors, hash tables, date etc. - java.io : Stream classes for I/O . - java.awt : Classes for implementing GUI – windows, buttons, menus etc. - java.net : Classes for networking . - java.applet : Classes for creating and implementing app.
• 4.
  Using System Packages •The packages are organised in a hierarchical structure .For example, a package named “java” contains the package “awt”, which in turn contains various classes required for implementing GUI (graphical user interface). Java “java” Package containing “lang”, “awt”,.. packages; Can also contain classes. awt package containing classes. Classes containing methods lang graphics font image awt
• 5.
  Accessing Classes fromPackages There are two ways of accessing the classes stored in packages: • Using fully qualified class name java.lang.Math.sqrt(x); • Import package and use class name directly import java.lang.Math Math.sqrt(x); • Selected or all classes in packages can be imported: • Implicit in all programs: import java.lang.*; • package statement(s) must appear first import package.class; import package.*;
• 6.
  Creating Packages Java supportsa keyword called “package” for creating user-defined packages. The package statement must be the first statement in a Java source file (except comments and white spaces) followed by one or more classes. package myPackage; public class ClassA { // class body } class ClassB { } Package name is “myPackage” and classes are considered as part of this package; The code is saved in a file called “ClassA.java” and located in a directory called “myPackage”.
• 7.
  Accessing a Package •As indicated earlier, classes in packages can be accessed using a fully qualified name or using a short- cut as long as we import a corresponding package. • The general form of importing package is: import package1[.package2][…].classname • Example: import myPackage.ClassA; import myPackage.secondPackage • All classes/packages from higher-level package can be imported as follows: import myPackage.*;
• 8.
  Using a Package •Let us store the code listing below in a file named“ClassA.java” within subdirectory named “myPackage”within the current directory (say “abc”). • package myPackage; • public class ClassA { • // class body • public void display() • { • System.out.println("Hello, I am ClassA"); • } • } • class ClassB { • // class body • }
• 9.
  Using a Package Withinthe current directory (“abc”) store the following code in a file named“ClassX.java” import myPackage.ClassA; public class ClassX { public static void main(String args[]) { ClassA objA = new ClassA(); objA.display(); } }
• 10.
  Compiling and Running •en ClassX.java is compiled, the compiler compiles it and places .class file in current directly. If .class of ClassA in subdirectory “myPackage” is not found, it comples ClassA also. • Note: It does not include code of ClassA into ClassX ✞ • When the program ClassX is run, java loader looks for ClassA.class file in a package called “myPackage” and loads it.
• 11.
  Using a Package Letus store the code listing below in a file named“ClassA.java” within subdirectory named“secondPackage” within the current directory (say“abc”). public class ClassC { // class body public void display() { System.out.println("Hello, I am ClassC"); } }
• 12.
  Using a Package •Within the current directory (“abc”) store the following code in a file named“ClassX.java” • import myPackage.ClassA; • import secondPackage.ClassC; • public class ClassY • { • public static void main(String args[]) • { • ClassA objA = new ClassA(); • ClassC objC = new ClassC(); • objA.display(); • objC.display(); • } • }
• 13.
  Output • Hello, Iam ClassA • Hello, I am ClassC
• 14.
  Thanks you
