Arduino Programming on Motor Control
This document describes 4 programs for controlling a DC motor using an Arduino. Program 1 controls the speed of a DC motor. Program 2 controls the acceleration and deceleration of a DC motor. Program 3 controls the rotational direction of a DC motor by setting the A and B pins to either CCW, CW, or stop. Program 4 is not described.
Arduino Programming on Motor Control
- 1. Department of Electricaland Electronic Engineering Khulna University of Engineering & Technology Khulna-9203 Course code : EE 3214 Sessional on Microprocessors, Micro-controllers and Peripherals Presented By Amit Kumer Podder Experiment No. 10
- 2. Design and implementationof DC motor speed control drive in Arduino environment Experiment Name
- 3. Spinning of DCMotor Program 01
- 4. Speed control ofDC Motor Program 02
- 5. Acceleration & Decelerationof DC Motor Program 03
- 6. Rotational direction controlof DC Motor A B Direction 0 0 Stop 0 1 CCW 1 0 CW 1 1 N/A Program 04
