Building a Highly Scalable, Open Source Twitter Clone

Building a Highly
Scalable, Open
Source Twitter Clone
Dan Diephouse (dan@netzooid.com)
Paul Brown (prb@mult.ifario.us)

Motivation
★ Wide (and growing) variety of
non-relational databases.
(viz. NoSQL — http://bit.ly/pLhqQ, http://bit.ly/17MmTk)

★ Twitter application model
presents interesting
challenges of scope and
scale.
(viz. “Fixing Twitter” http://bit.ly/2VmZdz)

Storage Metaphors
★ Key/Value Store
Opaque values; fast and simple.
★ Examples:
★ Cassandra* — http://bit.ly/EdUEt
★ Dynomite — http://bit.ly/12AYmf
★ Redis — http://bit.ly/LBtCh
★ Tokyo Tyrant — http://bit.ly/oU4uV
★ Voldemort – http://bit.ly/oU4uV

Key/Value
Key Value

1

2

3

Storage Metaphors
★ Document-Oriented
Unstructured content; rich queries.
★ Examples:
★ CouchDB — http://bit.ly/JAgUM
★ MongoDB — http://bit.ly/HDDOV
★ SOLR — http://bit.ly/q4gyi
★ XML databases...

Document-Oriented
ID=“dan-tweet-1”,
TEXT=“hello world”

ID=dan-tweet-2,
TEXT=“Twirp!”,
IN-REPLY-TO=“paul-tweet-5”

Storage Metaphors
★ Column-Oriented

Organized in columns; easily scanned.
★ Examples:
★ Cassandra* — http://bit.ly/EdUEt

★ BigTable — http://bit.ly/QqMYA
(available within AppEngine)

★ HBase — http://bit.ly/Zck7F
★ SimpleDB — http://bit.ly/toh0P
(Typica library for Java — http://bit.ly/22kxZ4)

Column-Oriented
Name Date Tweet Text
Bob 20090506 Eating dinner.
Dan 20090507 Is it Friday yet?
Dan 20090506 Beer me!
Ralph 20090508 My bum itches.

Index Name Index Date Index Tweet Text
0 Bob 0 20090506 0 Eating dinner.
1 Dan 1 20090507 1 Is it Friday yet?
2 Dan 2 20090506 2 Beer me!
3 Ralph 3 20090508 3 My bum itches.

Storage Storage Storage

Every Store is Special.

★ Lots of different little tweaks
to the storage model.
★ Widely varying levels of
maturity.
★ Growing communities.
★ Limited (but growing) tooling,
libraries, and production
adoption.

Reliability Through
Replication
★ Consistent hashing to assign
keys to partitions.
★ Partitions replicated on
multiple nodes for
redundancy.
★ Minimum number of successful
reads to consider a write
complete.

Reliability Through
Replication
PUT (k,v)

Client

Web UI
http://tat1.datapr0n.com:8080

Stores
★ Tweets
Individual tweets.

★ Friends’ Timeline
Fixed-length timelines.

★ Users
Info and followers.

★ Command Queue
Actions to perform (tweet, follow, etc.).

Data
★ Command (Java serialization)
Keyed by node name, increasing ID.
★ Tweets (Java serialization)
Keyed by user name, increasing ID.
★ FriendsTimeline (Java serialization)
Keyed by username.
List of date, tweet ID.
★ Users (Java serialization)
Keyed by username.
Followers (list), Followed (list), last tweet ID.

Life of a Tweet, Part I
1

Beer me. Users
1.User tweets. 2

2.Find next
tweet ID for 3 Commands

Web Tier
user.
3.Store “tweet Friends
Timeline

for user”
command.
Tweets

Life of a Tweet, Part II
Where's
1. Read next command. Demi with
Users
my beer?!?
2. Store tweet in
user’s timeline 1
(Tweets). Commands

4

Web Tier
3. Store tweet ID in
friends’
3
timelines. Friends
Timeline
(Requires *many*
operations.)
2

4. DELETE command. Tweets

Some Patterns
★ “Sequences” are implemented
as race-for-non-collision.
★ “Joins” are common keys or
keys referenced from values.
★ “Transactions” are idempotent
operations with DELETE at the
end.

Operations
★ Deploy to Amazon EC2
★ 2 nodes for Voldemort
★ 2 nodes for Tomcat
★ 1 node for Cacti
★ All “small” instances w/RightScale CentOS
5.2 image.
★ Minor inconvenience of “EBS” volume for
MySQL for Cacti.
(follow Eric Hammond’s tutorial — http://bit.ly/OK5LZ)

Deployment
★ Lots of choices for automated rollout
(Chef, Capistrano, etc.)
★ Took simplest path — Maven build, Ant
(scp/ssh and property substitution
tasks), and bash scripts.
for i in vn1 vn2; do

ant -Dnode=${i} setup-v-node

done

★ Takes ~30 seconds to provision a Tomcat
or Voldemort node.

Dashboarding
★ As above, lots of choices
(Cacti — http://bit.ly/qV4gz, Graphite — http://bit.ly/466NAx, etc.)

★ Cacti as simplest choice.
yum install -y cacti

★ Vanilla SNMP on nodes for host
data.
★ Minimal extensions to Voldemort
for stats in Cacti-friendly
format.

Performance
★ 270 req/sec for getFriendsTimeline against
web tier.
★ 21 GETs on V stores to pull data.
★ 5600 req/sec for V is similar to
performance reported at NoSQL meetup (20k
req/sec) when adjusted for hardware.
★ Cache on the web tier could make this
faster...
★ Some hassles when hammering individual keys
with rapid updates.

Take Aways
★ Linked-list representation deserves some thought
(and experiments).
Dynomite + Osmos (http://bit.ly/BYMdW)

★ Additional use cases (search, rich API, replies,
direct messages, etc.) might alter design.
★ BigTable/HBase approach deserves another look.
★ Source code is available; come and git it.

http://github.com/prb/bigbird

git://github.com/prb/bigbird.git

Coordinates
★ Dan Diephouse (@dandiep)
dan@netzooid.com
http://netzooid.com
★ Paul Brown (@paulrbrown)
prb@mult.ifario.us
http://mult.ifario.us/a
