UiPath Automation Suite Installation (Hands-On) [2/3]

UiPath Automation Suite Installation (Hands-On) [2/3]

• 1.
  UiPath Automation Suite: CommunityWorkshop Session 2/3: UiPath Automation Suite Installation (Hands-On)
• 2.
  2 Ramkrishna Kadiya Technical AccountManager UiPath https://www.linkedin.com/in/ramkrishna-kadiya-a5386315/ Pawan Rathore Senior Technical Account Manager UiPath https://www.linkedin.com/in/pawankrathore/ Speakers
• 3.
  3 Agenda 3 1. Deployment Modes 2.Prerequisites - 24.10.x • Hardware and software prerequisites • Deployment types & capacity planning • Setting up DNS 3. Prerequisite checks 4. VM Disk Configuration 5. DB connectivity & Walkthrough of cluster config JSON 6. Installation of temp docker registry 7. Kubernetes Infra layer installation of server + agent 8. Initiate/Kick off - Service and fabric layer installation
• 4.
  4 Type Details Single Node •Default Mode • Supported for evaluation and demo scenarios • Not suitable for production usage Multi Node • Recommended for production usage • Two variations: • Lite Mode • Infra & Shared components in HA • Services are set to non-HA • Can set specific services to HA mode • HA Mode: • Fully Enabled HA Deployment Modes
• 5.
  5 Components Single Node– Minimum Requirements Multi Node – Minimum Requirements Processor per cluster 32 (v-)CPU/cores 96 (v-)CPU/cores Min. Processor per node N/A 8 (v-)CPU/cores RAM 64 GB 192 GB Min. RAM per node N/A 16 GB Cluster disks 256 GB SSD (Min IOPS: 1100) 256 GB SSD (Min IOPS: 1100) Data disk (Only on server nodes) 512 GB SSD (Min IOPS: 1100) 512 GB SSD (Min IOPS: 1100) etcd disk (Only on server nodes) 16 GB SSD (Min IOPS: 1100) 16 GB SSD (Min IOPS: 1100) UiPath bundle disk • Required on first node • Required only for offline installation • Required only if external registry not available 512 GB SSD (Min IOPS: 1100) 512 GB SSD (Min IOPS: 1100) Objectstore disk (Only on server node and only when external objectstore is not available) 512 GB SSD (Min IOPS: 1100) 512 GB SSD (Min IOPS: 1100) Ceph data backup disk (Required only in single-node RKE2 setup with in-cluster storage) 512 GB SSD (Min IOPS: 1100) 512 GB SSD (Min IOPS: 1100) AI Center disk 51 GB Minimum 105 GB recommended for 1 training pipeline 51 GB Minimum 105 GB recommended for 1 training pipeline Operating System RHEL (8.8, 8.9, 8.10, 9.2, 9.4, 9.6) & supporting packages RHEL (8.8, 8.9, 8.10, 9.2, 9.4, 9.6) & supporting packages Hardware and software prerequisites Prerequisites - 24.10.x
• 6.
  6 Components Requirements Task Mining– Agent Node CPU: 20 RAM: 60 GB Cluster & State Disk: 256 GB (Min IOPS: 1100) Data Disk: N/A Automation Suite Robot – Agent Node AI Center & DU Requirements – Agent Node Hardware and software prerequisites Prerequisites - 24.10.x – Continued … Robot Size CPU Memory Storage Small 0.5 1 GB 1 GB Standard 1 2 GB 2 GB Medium 2 4 GB 4 GB Large 6 10 GB 10 GB Use CPU RAM GPU Disk (GB) Min. for service (ML Skill, One replica) 0.6 2GB N/A 20 GB on rancher partition Min. for training (pipeline) 1 4GB N/A 20 GB on rancher partition Min.51 GB AI-center disk partition (Recommended 105 GB) DU model serving (ML Skill, one replica) 1 4GB N/A 20 GB on rancher partition DU Model training 2 24GB Strongly Recommended 20 GB on rancher partition Min.51 GB AI center disk partition (Recommended 105 GB)
• 7.
  7 Components Requirements Computer VisionRequirements MS SQL Server • Microsoft SQL Server 2016, 2017, 2019, and 2022 Standard and Enterprise editions • Azure SQL Database • Azure SQL managed Instance • Aamzon Relational Database Service • Minimum requirements: • 8 (v-)CPU • 32 GB RAM • 256 GB SSD NFS Server for backup • Linux based on-premises or cloud managed NFS server (Versions: NFSv3/NFSv4) • 4 vCPU • 8 GB RAM • 1 TB Storage Hardware and software prerequisites Prerequisites - 24.10.x – Continued … Component Minimum Recommended Memory 8 GB 16 GB CPU 2 Core with AVX2 enabled 2 Core with AVX2 enabled GPU 8 GB VRAM 16 GB VRAM Storage Min 30 GB Free Min 30 GB Free
• 8.
  8 Online Deployment Deployment Types& Capacity Planning • AS requires access to internet during installation and while running • UiPath products and registry are stored either on UiPath registry or UiPath trusted third party store • Access can be restricted using firewall or proxy server by blocking the traffic which is not required by Automation Suite • Easier, faster, require less hardware to install and manage • Can’t switch from online to offline deployment post installation
• 9.
  9 Offline Deployment Deployment Types& Capacity Planning – Continued… • Offline deployment is also known as air-gapped deployment • Isolated from internet • Requires installation of additional registry to store UiPath Products’ container images and binaries • Additional hardware required to upload binaries/registries • Increased complexity and time required for installation • Can’t switch from offline to online deployment post installation
• 10.
  10 Deployment Options Deployment Types& Capacity Planning – Continued… • UiPath provides flexibility to deploy complete Automation Suite platform on containerised platform like: • AKS: Azure Kubernetes Services • EKS: Elastic Kubernetes Services • Openshift • Linux Embedded Capacity Planning • UiPath offers a capacity planning calculator which will help your determine hardware requirements to set-up Automation Suite. • https://docs.uipath.com/automation-suite/2024.10/calculator
• 11.
  11 Setting up DNS ApplicationDomain Example URL Automation Suite fqdn automationsuite.mycompany.com Application Lifecycle Management (ALM) alm.{{fqdn}} alm.automationsuite.mycompany.com Monitoring / Observability monitoring.{{fqdn}} monitoring.automationsuite.mycompany.com Object Store objectstore.{{fqdn}} objectstore.automationsuite.mycompany.com Docker Registry registry.{{fqdn}} registry.automationsuite.mycompany.com Insights insights.{{fqdn}} insights.automationsuite.mycompany.com Apps apps.{{fqdn}} apps.automationsuite.mycompany.com Configuring DNS using public domain register Type Host Value A Record (or CName) automationsuite (Or subdomain to access Automation Suite) • For A Record: IP Address of load balancer • For CName: DNS name associated with LB A Record (or CName) *.automationsuite (or a subdomain to access Automation Suite) • For A Record: IP Address of load balancer • For CName: DNS name associated with LB
• 12.
  Thank you
