Design and Analysis of Algorithms (Greedy Algorithm)

Design and Analysis of Algorithms
Greedy Algorithms

2
Greedy Algorithm
• Algorithms for optimization problems typically go
through a sequence of steps, with a set of choices at
each step.
• Greedy algorithms make the choice that looks best at
the moment.
– That is, it makes such a decision in the hope that this will
lead to a globally optimal solution
• This locally optimal choice may lead to a globally
optimal solution (i.e., an optimal solution to the
entire problem).

3
When can we use Greedy algorithms?
We can use a greedy algorithm when the following are true:
1) The greedy choice property: A A(greedy) choice.
2) The optimal substructure property: The optimal solution
contains within its optimal solutions to subproblems.

4
An Activity Selection Problem
(Conference Scheduling Problem)
• Input: A set of activities S = {a1,…, an}
• We have n proposed activities that wish to use a
resource, such as a lecture hall, which can serve only
one activity at a time.
• Each activity has start time and a finish time
–ai=(si, fi)
• Two activities are compatible if and only if their interval
does not overlap
• Output: a maximum-size subset of mutually
compatible activities

5
The Activity Selection Problem
• Here are a set of start and finish times
• What is the maximum number of activities that can be
completed?
• {a3, a9, a11} can be completed
• But so can {a1, a4, a8’ a11} which is a larger set
• But it is not unique, consider {a2, a4, a9’ a11}

6
Input: list of time-intervals L
Output: a non-overlapping subset S of the intervals
Objective: maximize |S| 3,7
2,4
5,8
6,9
1,11
10,12
0,3

7
Input: list of time-intervals L
Output: a non-overlapping subset S of the
intervals
Objective: maximize |S|
3,7
2,4
5,8
6,9
1,11
10,12
0,3
Answer = 3

8
Algorithm 1:
1. sort the activities by the starting time
2. pick the first activity “a”
3. remove all activities conflicting with “a”
4. repeat

9
Algorithm 1:
4. repeat

10
Algorithm 1:
4. repeat

11
Algorithm 2:
1. sort the activities by length
2. pick the shortest activity “a”
4. repeat

12
Algorithm 2:
4. repeat

13
Algorithm 2:
4. repeat

14
Algorithm 3:
1. sort the activities by ending time
2. pick the activity which ends first
3. remove all activities conflicting with a
4. repeat

15
Algorithm 3:
4. repeat

16
Algorithm 3:
4. repeat

17
Algorithm 3:
4. repeat

18
Algorithm 3:
2. pick the activity “a” which ends first
4. repeat
Theorem:
Algorithm 3 gives an optimal solution to
the activity selection problem.

19
Activity Selection Algorithm
Idea: At each step, select the activity with the smallest finish time
that is compatible with the activities already chosen.
Greedy-Activity-Selector(s, f)
n <- length[s]
A <- {1} {Automatically select first
activity}
j <- 1 {Last activity selected so far}
for i <- 2 to n do
if si >= fj then
A <- A U {i} {Add activity i to the set}
j <- i {record last activity added}
return A
The idea is to always select the activity with the earliest finishing
time, as it will free up the most time for other activities.

20
• Here are a set of start and finish times
• What is the maximum number of activities that can be
completed?
• {a3, a9, a11} can be completed
• But so can {a1, a4, a8’ a11} which is a larger set
• But it is not unique, consider {a2, a4, a9’ a11}

21
Interval Representation
Added in optimal Solution
Not Observed yet
Removed from the list

22
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

23
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

24
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

25
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

26
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

27
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

28
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

29
Why this Algorithm is Optimal?
• We will show that this algorithm uses the
following properties
• The problem has the optimal substructure
property
• The algorithm satisfies the greedy-choice
property
• Thus, it is Optimal

30
Optimal Substructure Property
• Base Case: For the smallest subproblem of size 1 (only one
activity), the optimal solution is trivially the activity itself.
• Inductive Hypothesis: Assume that we have already proven that
the optimal solution can be constructed for any subset of activities
with size k, where 1 ≤ k ≤ n - 1.

31
Inductive Step: Now we want to prove that the optimal solution can
be constructed for a subset of activities with size k + 1.
Let's consider the set of activities {A1, A2, ..., Ak+1}. Since the activities
are sorted by finishing times,
the last activity in this set, Ak+1, will have the maximum finish time
among all activities.
We have two cases:
First case: Activity Ak+1 is included in the optimal solution.
• In this case, we need to find an optimal solution for the remaining
activities {A1, A2, ..., Ak} that are non-overlapping with Ak+1.
• By our inductive hypothesis, we know that an optimal solution can be
constructed for these k activities.
• Combining Ak+1 with this optimal solution gives us an optimal solution for
the entire set {A1, A2, ..., Ak+1}.

32
First case: Activity Ak+1 is included in the optimal solution.
• In this case, we need to find an optimal solution for the remaining activities {A1, A2, ..., Ak}
that are non-overlapping with Ak+1.
• By our inductive hypothesis, we know that an optimal solution can be constructed for
these k activities.
• Combining Ak+1 with this optimal solution gives us an optimal solution for the entire set
{A1, A2, ..., Ak+1}
Second Case: Activity Ak+1 is not included in the optimal solution.
• In this case, we simply need to find an optimal solution for the activities
{A1, A2, ..., Ak}, which we have already assumed possible by our inductive
hypothesis.
Since we've covered both cases, we can conclude that the optimal solution
for the set {A1, A2, ..., Ak+1} can be constructed from the optimal solutions
of the smaller subproblems {A , A , ..., A },

33
Greedy-Choice Property
• Show there is an optimal solution that begins with a greedy
choice (with activity 1, which as the earliest finish time)
• Suppose A  S in an optimal solution
– Order the activities in A by finish time. The first activity in A is k
• If k = 1, the schedule A begins with a greedy choice
• If k  1, show that there is an optimal solution B to S that begins with the
greedy choice, activity 1
– Let B = A – {k}  {1}
• f1  fk  activities in B are disjoint (compatible)
• B has the same number of activities as A
• Thus, B is optimal

Example of Greedy Algorithm
• Fractional Knapsack
• Huffman Coding
• Minimum Spanning Tree – Prims and Kruskal’s
• Activity Selection Problem
• Dijkstra’s Shortest Path Algorithm
• Network Routing
• Job sequencing with deadlines
• Coin change problems
• Graph Coloring: Greedy algorithms can be used to color
a graph (though not necessarily optimally) by assigning
the next available color to a vertex.
34

35
Designing Greedy Algorithms
1. Cast the optimization problem as one for which:
• we make a choice and are left with only one subproblem
to solve
2. Prove the GREEDY CHOICE
• that there is always an optimal solution to the original
problem that makes the greedy choice
3. Prove the OPTIMAL SUBSTRUCTURE:
• the greedy choice + an optimal solution to the resulting
subproblem leads to an optimal solution

36
Example: Making Change
• Instance: amount (in cents) to return to customer
• Problem: do this using fewest number of coins
• Example:
– Assume that we have an unlimited number of coins of
various denominations:
– 1c (pennies), 5c (nickels), 10c (dimes), 25c (quarters), 1$
(loonies)
– Objective: Pay out a given sum $5.64 with the
smallest number of coins possible.

37
The Coin Changing Problem
• Assume that we have an unlimited number of coins of various
values:
• 1c (pennies), 5c (nickels), 10c (dimes), 25c (quarters), 1$ (loonies)
• Objective: Pay out a given sum S with the smallest number of
coins possible.
• The greedy coin changing algorithm:
• This is a (m) algorithm where m = number of values.
while S > 0 do
c := value of the largest coin no larger than S;
num := S / c;
pay out num coins of value c;
S := S - num*c;

38
Example: Making Change
• E.g.:
$5.64 = $2 +$2 + $1 +
.25 + .25 + .10 +
.01 + .01 + .01 +.01

39
Making Change – A big problem
• Example 2: Coins are valued $.30, $.20, $.05,
$.01
– Does not have greedy-choice property, since $.40 is
best made with two $.20’s, but the greedy solution will
pick three coins (which ones?)

40
The Fractional Knapsack Problem
• Given: A set S of n items, with each item i having
– bi - a positive benefit
– wi - a positive weight
• Goal: Choose items with maximum total benefit but with weight at
most W.
• If we are allowed to take fractional amounts, then this is the fractional
knapsack problem.
– In this case, we let xi denote the amount we take of item i
– Objective: maximize
– Constraint:

S
i
i
i
i w
x
b )
/
(
i
i
S
i
i w
x
W
x 




0
,

41
Example
• Given: A set S of n items, with each item i having
– bi - a positive benefit
– wi - a positive weight
• Goal: Choose items with maximum total benefit but with total weight at
most W.
Weight:
Benefit:
1 2 3 4 5
4 ml 8 ml 2 ml 6 ml 1 ml
$12 $32 $40 $30 $50
Items:
Value: 3
($ per ml)
4 20 5 50
10 ml
Solution: P
• 1 ml of 5
50$
• 2 ml of 3
40$
• 6 ml of 4
30$
• 1 ml of 2
4$
“knapsack”

42
The Fractional Knapsack Algorithm
• Greedy choice: Keep taking item with highest value (benefit to
weight ratio)
– Since
Algorithm fractionalKnapsack(S, W)
Input: set S of items w/ benefit bi and weight wi; max. weight W
Output: amount xi of each item i to maximize benefit w/ weight at most W
for each item i in S
xi  0
vi  bi / wi {value}
w  0 {total weight}
while w < W
remove item i with highest vi
xi  min{wi , W - w}
w  w + min{wi , W - w}

 


S
i
i
i
i
S
i
i
i
i x
w
b
w
x
b )
/
(
)
/
(

43
The Fractional Knapsack Algorithm
• Running time: Given a collection S of n items, such that each item i
has a benefit bi and weight wi, we can construct a maximum-benefit
subset of S, allowing for fractional amounts, that has a total weight W in
O(nlogn) time.
– Use heap-based priority queue to store S
– Removing the item with the highest value takes O(logn) time
– In the worst case, need to remove all items
