  T E AM M E M B E R M D . R I Y A D 2 0 1 7 - 1 - 8 - 0 2 7 U M A M A T A S N I M T A N I S H A 2 0 1 7 - 1 - 8 - 0 2 8 A Y A N D A S G U P T A 2 0 1 7 - 1 - 8 - 0 3 2 Project Title : Flame Detection By Using Arduino UNO R3 and Bluetooth Module
• 2.
  PROBLEM DEFINITION: To detect theflame generated in the machine Fire can damage machine parts even the whole machine
• 3.
  We can take necessarysteps to stop later consequences Gives us signal by glowing LED and buzzer sound when flame is produced Ensure the safety of the machine Can give signal through bluetooth module within a certain distance SIGNIFICANCE: Increase the lifetime
• 4.
  NOVELTY: Connected through bluetooth modulePortable Light weight Low cost
• 5.
  Solution Approach:
• 6.
  Flame Sensor Buzzer LED Lcd Display
• 7.
  ITEM NAME QUANTITYCOST Arduino UNO R3 02 410.09*2 Bluetooth module 02 380*3 LED 01 1.40*1 Resistor(330ohm) 01 10*1 Breadboard 02 85.32*2 Jumper wire 20 1.80*20 Battary (9v) 02 25*2 Battery connector 02 29.45*2 Buzzer 01 15*1 Flame sensor 01 755.50*1 Lcd Display 01 135.23*1 Total Cost = 3192.85 tk (only) BUDGET
• 8.
  PROGRESS:
