Kubernetes networking in AWS
- 1.
- 2.
- 3. AWS Infrastructure Components Region AZ AZ VPC SecurityGroup Security Group Routing Table Instance Instance Internet GW VPC router Subnet Virtual Private GW Internet Elastic IP Corporate Instance Eni (interface) Customer GW Eni Instance Subnet Regions - used to manage network latency and regulatory compliance per country. No Data replication outside a region Availability Zones - at least two in a region. Designed for fault isolation. Connected to multiple ISPs and different power sources. Interconnected using LAN speed for inter-communications within the same region VPC – spans all region’s AZs. Used to create isolated private cloud within AWS. IP ranges allocated by the customer. Networking – interfaces, subnets, routing tables and gateways (Internet, NAT and VPN). Security – security groups Interface (ENI) – can include primary, secondary or elastic IP. Security group attaches to it. Independent from the instance (even though primary interface cannot be detached from an instance). Subnet – connects one or more ENIs, can talk to another subnet only through a L3 router. Can connected to only one routing table. Cannot span AZs Routing table – decides where network traffic goes. May connect to multiple subnets. 50 routes limit per table
- 4. VPC Security Components Securitygroup - virtual firewall for the instance to control inbound and outbound traffic. • Applied on ENI (instance) only • No deny rules • Stateful – return traffic implicitly allowed • All rules evaluated before decision • Up to five per instance Network ACL- virtual IP filter on the subnet level • Applied on subnet only • Allows deny rules • Stateless – return traffic should be specified • First match takes Region AZ AZ VPC Security Group Security Group Routing Table Instance Instance Internet GW VPC router Subnet Virtual Private GW Internet Elastic IP Corporate Instance Eni (interface) Customer GW Eni Instance Subnet Network ACL
- 5. Network segmentation VPC isolation– the best way for separating customers (obvious) and different organizations without messing with security groups. • AWS VPC – Great even for internal zoning. No need for policies • Security group – Statefull and flexible. Network location agnostic • Network ACL – good for additional subnet level control VPC R&D Security Group Security Group Routing Table Instance Instance VPC router Subnet Virtual Private GW Instance Eni (interface) Eni Instance Subnet Network ACL VPC - Production Security Group Security Group Routing Table Instance Instance VPC router Subnet Virtual Private GW Instance Eni (interface) Eni Instance Subnet Network ACL Implicit network segmentation Explicit instance segmentation Explicit network segmentation
- 6. VPC integration withother AWS services Elastic load balancing – • Types – Classic and application • Classic is always Internet exposed • Application LB can be internal • ELB always sends traffic to private IP backends • Application ELB can send traffic to containers Region AZ AZ VPC Security Group Security Group Routing Table Instance Instance Internet GW VPC router Subnet Virtual Private GW Internet Elastic IP Corporate Instance Eni (interface) Customer GW Eni Instance Subnet Internal ELB Outer ELB
- 7. VPC integration withother AWS services AWS Simple Storage Service (S3) - • Opened to the internet • Data never spans multiple regions unless transferred • Data spans multiple AZs • Connected to VPC via a special endpoint • The endpoint considered and interface in the routing table • Only subnets connected to the relevant routing table can use the endpoint Region AZ AZ VPC Security Group Security Group Routing Table Instance Instance Internet GW VPC router Subnet Virtual Private GW Internet Elastic IP Corporate Instance Eni (interface) Customer GW Eni Instance Subnet Endpoint
- 8. VPC integration withother AWS services Lambda – • Service that runs a selected customer’s code • Runs over a container located in AWS own compute resources • Initiate traffic from an IP outside of the VPC • Single Lambda function can access only one VPC • Traffic from Lambda to endpoints outside the VPC should be explicitly allowed on the VPC Region AZ AZ VPC Security Group Security Group Routing Table Instance Instance Internet GW VPC router Subnet Virtual Private GW Internet Elastic IP Corporate Instance Eni (interface) Customer GW Eni Instance Subnet Endpoint
- 9. Inter-region interface VPC isolation– the best way for separating customers (obvious) and different organizations without messing with security groups. • Complete isolation • Only through the internet over VPN connection Amsterdam Security Group Security Group Routing Table Instance Instance VPC router Subnet Virtual Private GW Instance Eni (interface) Eni Instance Subnet US Virginia Security Group Security Group Routing Table Instance Instance VPC router Subnet Virtual Private GW Instance Eni (interface) Eni Instance Subnet Network ACL Internet Internet GWInternet GW
- 10.
- 11. Containerized applications networking Whatare we looking for? • Service discovery – automated reachability knowledge sharing between networking components • Deployment – standard and simple. No heavy network experts involvement. • Data plane – direct access (no port mapping), fast and reliable • Traffic type agnostic – multicast, IPv6 • Network features - NAT, IPAM, QoS • Security features - micro-segmentation, access-control, encryption… • Public cloud ready – Multi VPC and AZs support, overcome route table, costs. • Public cloud agnostic - dependency on the provider’s services – as minimal as possible
- 12. Three concepts around •Overlay – A virtual network decoupled from the underlying physical network using a tunnel (most common - VXLAN) • Underlay – attaching to the physical node’s network interfaces • Native L3 routing - L3 routing, advertising containers/pod networks to the network. No overlay
- 13. Overlay only approach Implementations– Flannel, Contiv, Weave, Nuage Data Plane – • Underlying network transparency • Via kernel space – much less network latency • Overhead - adds 50 bytes to the original header. • Traffic agnostic- Passes direct L2 or routed L3 traffic between two isolated segments. IPv4/IPV6/Multicast Control plane – • Service and network discovery – key/value store (etcd, Consul …) • VNI field - identifies layer 2 networks allowing isolation between them. Routing between two separate L3 networks – via an external router (VXLAN aware) • VTEP (VXLAN tunnel endpoints) – The two virtual interfaces terminating the tunnel. Instances’ vNIC
- 14. Underlay - MACVLAN •Attaches L2 network to the node’s physical interface by creating a sub-interface • Each of the sub-interfaces use different MAC • Pod belongs to the attached network will be directly exposed to the underlying network w/o port mapping or overlay • Bridge mode - most commonly used, allows pods, containers or VMs to internally interconnect - traffic doesn’t leave the host • AWS – • Disable IP src/dst check • Promiscuous mode on the parent nic • Verify MAC address per NIC limitation POD Container Container Bridge Eth0.45 MACVLAN veth eth0 Eth0 EXT
- 15. Native L3 onlyapproach Implementation – Calico, Romana Data Plane – • No overlays – direct container to container (or pod) communications using their real IP addresses, leveraging routing decisions made by container hosts and network routers (AWS route table) Control plane – • Containers/Pods/Services IPs being published to the network using routing protocol such as BGP • Optional BGP peering – between containers nodes for inter-container communications and/or with upstream router for external access • Large scale – route-reflector implementation may be used • Due to the L3 nature, native IPv6 is supported • Optionally NAT is supported for outgoing traffic
- 16. Networking models -Comparison CategoryModel Overlay L3 routing Comments Simple to deploy Yes No L3 BGP requires routing config Widely used Yes No VXLAN – supported by most plugins Traffic type agnostic Yes Yes* *Driver support dependent Allows IP duplication Yes No L3 need address management Public Cloud friendly Yes No L3 – requires special config on AWS routing tables* HA - two different AZ’s subnets still requires tunneling** Host local routing No Yes Inter-subnet routing on same host goes out External plugins – overcome – split routing Underlying network independency Yes No L3 needs BGP peering config for external comm. Performance Yes* Yes *Depends on data path – user or kernel space Network Efficiency No Yes Overlay adds overhead
- 17. Common Implementation Concepts •The majority of plugins – combine overlay (mostly VXLAN) and L3 • Subnet allocated per node (Nuage is an exception) • Based on agent installed on the node (project proprietary or Open vSwitch) • Local routing on the node between different subnets • Support routing to other nodes (needs L2 networks between nodes) • Public clouds integration provided for routing table update (limited comparing to standard plugins) • Performance - Data path in Kernel space • Distributed or policy based (SDN)
- 18. Flannel (CoreOS) –The proprietary example • Used for dual OVS scenarios (Openstack) • Flanneld agent on the node – allocates a subnet to the node and register it in the etcd store installed on each node • No Security policy currently supported - A new project, Canal, combines Flannel and Calico for a whole network and security solution • Subnet cannot span multiple hosts Three implementations: • Overlay – UDP/VXLAN – etcd used for control plane • Host-gw – direct routing over L2 network with routing on the node’s routing table – Can be used in AWS also – preforms faster • AWS-VPC – direct routing over AWS VPC routing tables. Dynamically updates the AWS routing table (50 route entries limits in a routing table. If more needed, VXLAN can be used).
- 19. Flannel Direct Flanneld Node1Master Flanneld Namespace Docker0 Linux Bridge 172.17.43.1 Namespace Container veth etcd AWSVPC Namespace Docker0 Linux Bridge 172.17.42.1 Namespace Container veth Flanneld Flanneld AWS route table AWS-VPC - Control Plane Direct - Data Plane Flanneld Flanneld Host route table Host route table HOST-GW - Control Plane No overlappingNo overlapping eth0eth0 veth 172.17.43.2 veth 172.17.42.2 Static route via node1
- 20. Flannel OVERLAY Flanneld KUB-NODEKUB-MASTER Flanneld Namespace Docker0 Linux Bridge 172.17.42.1 Namespace Container veth 172.17.42.2 veth etcdetcd Namespace Docker0 Linux Bridge 172.17.42.1 Namespace Container veth 172.17.42.2 veth VXLAN Flanneld Flanneld VXLAN- Control Plane Overlay - Data Plane VXLAN vtep VXLAN vtep vxlanvxlan No overlappingOverlapping
- 21. OpenShift Networking over Kubernetes OVS-basedsolution Concepts Implementation alternatives
- 22. PAUSE Container PAUSE Container etcd DNS Docker POD • Agroup of one or more containers • Contains containers which are mostly tightly related • Mostly ephemeral in nature • All containers in a pod are in the same physical node • The PAUSE container maintains the networking KUBE-PROXY • Assigns a listening port for a service • Listen to connections targeted to services and forwards them to the backend pod • Two modes – “Userspace” and “IPTables” Kubelet • Watches for pods scheduled to node and mounts the required volumes • Manages the containers via Docker • Monitors the pods status and reports back to the rest of the system Replication Controller Ensures that a specified number of pod “replicas” are running at any time Creates and destroys pods dynamically DNS Maintains DNS server for the cluster’s services etcd Key/Value store the API server All cluster data is stored here Access allowed only to API server API Service The front-end for the Kubernetes control plane. It is designed to scale horizontally
- 23. So why notDocker’s default networking? • Non-networking reason - drivers integration issues and low level built-in drivers (at least initially) • Scalability (horizontality) – Docker’s approach to assign IPs directly to containers limits scalability for production environment with thousands of containers. Containers network footprint should be abstracted • Complexity – Docker’s port mapping/NAT requires messing with configuration, IP addressing management and applications’ external port coordination • Nodes resource and performance limitation – Docker’s port mapping might suffer from ports resource limitations. In addition, extra processing required on the node • CNI model was preferred over the CNM, because of the container access limitation
- 24. Kubernetes native networking •IP address allocation – IP give to pods rather that to containers • Intra-pod containers share the same IP • Intra-pod containers use localhost to inter-communicate • Requires direct multi-host networking without NAT/Port mapping • Kubernetes doesn’t natively give any solution for multi-host networking. Relies on third party plugins: Flannel, Weave, Calico, Nuage, OVS etc. • Flannel was already discussed previously as an example to overlay networking approach • OVS will be discussed later as OVS based networking plugins • Nuage solution will be separately dicussed
- 25. Kubernetes - Pod WhenPOD is created with containers, the following happens: • “PAUSE” container created – • “pod infrastructure” container – minimal config • Handles the networking by holding the networking namespace, ports and IP address for the containers on that pod • The one that actually listens to the application requests • When traffic hits, it’s redirected by IPTABLES to the container that listens to this port • “User defined” containers created – • Each use “mapped container” mode to be linked to the PAUSE container • Share the PAUSE’s IP address apiVersion: v1 kind: Pod metadata: labels: deployment: docker-registry-1 deploymentconfig: docker-registry docker-registry: default generateName: docker-registry-1- spec: containers: - env: - name: OPENSHIFT_CA_DATA value: ... - name: OPENSHIFT_MASTER value: https://master.example.com:8443 ports: - containerPort: 5000 protocol: TCP resources: {} securityContext: { ... } dnsPolicy: ClusterFirst
- 26. Kubernetes - Service •Abstraction which defines a logical set of pods and a policy by which to access them • Mostly permanent in nature • Holds a virtual IP/ports used for client requests (internal or external) • Updated whenever the set of pods changes • Use labels and selector for choosing the backend pods to forward the traffic to When a service is created the following happens: • IP address assigned by the IPAM service • The kube-proxy service on the worker node, assigns a port to the new service • Kube-proxy generates iptables rules for forwarding the connection to the backend pods • Two Kube-proxy modes…. apiVersion: v1 kind: Service metadata: name: docker-registry spec: selector: docker-registry: default portalIP: 172.30.136.123 ports: - nodePort: 0 port: 5000 protocol: TCP targetPort: 5000
- 27. Kube-Proxy Modes Kube-Proxy alwayswrites the Iptables rules, but what actually handles the connection? Userspace mode – Kube-proxy is the one that forwards connections to backend pods. Packets move between user and kernel space which adds latency, but the application continues to try till it finds a listening backend pod. Also debug is easier Iptables mode – Iptables from within the kernel, directly forwards the connection to the pod. Fast and efficient but harder to debug and no retry mechanism IptablesConnection Connection Kube-proxy service Connection pod Writes iptables rules according to service definition IptablesConnection Kube-proxy service pod Writes iptables rules according to service definition
- 28. OpenShift SDN -Open Vswitch (OVS) – The foundation • A multi-Layer open source virtual switch • Doesn’t support native L3 routing need the Linux kernel or external componenet • Allows network automation through various programmatic interfaces as well as built-in CLI tools • Supports: • Port mirroring • LACP port channeling • Standard 802.1Q VLAN trunking • IGMP v1/2/3 • Spanning Tree Protocol, and RTSP • QoS control for different applications, users, or data flows • port level traffic policing • NIC bonding, source MAC addresses LB, active backups, and layer 4 hashing • OpenFlow • Full IPv6 support • kernel space forwarding • GRE, VXLAN and other tunneling protocols with additional support for outer IPsec
- 29. Linux Network Namespace •Logically another copy of the network stack, with its own routes, firewall rules, and network devices • Initially all the processes share the same default network namespace from the parent host (init process) • A pod is created with a “host container” which gets its own network namespace and maintains it • “User containers” within that pod join that namespace POD Container Container localhost PAUSE br0 (OVS) POD Container Container localhost PAUSE Default Namespace eth0 veth eth0 eth0 veth Namespace
- 30. OpenShift SDN -OVS Management Tun0 - OUT User space Kernel space vETH ovs-vsctl ovs-dpctlovs-appctl Container OVSDB – configures and monitors the OVS itself (bridges, ports..) Configures and monitors the ovsdb: bridges, ports, flows OpenFlow – programs the OVS daemon with flow entries for flow-based forwarding The actual OVS daemon • Process openflow messages • Manage the datapath (which actually in kernel space) • Maintain two flow table (exactly flow & wildcard flow) Sends commands to OVS daemon Example: MAC tables Configures and monitors the OVS kernel module
- 31. OpenShift SDN –L3 routing 1. OVS doesn’t support native L3 routing 2. L3 routing between two subnets done by the parent host’s networking stack 3. Steps (one alternative) 1. Creating two per-VLAN OVS 2. Creating two L3 sub- interfaces on the parent host 3. Bridging the two sub- interfaces to both OVS bridges 4. Activating IP forwarding on the parent host Eth0.1 0 Eth0.2 0 Note: The L3 routing can be done using plugins such as Flannel, Weave and others
- 32. 10.1.0.2 POD PAUSE Contai ner Contai ner localhost veth eth0 OpenShift SDN– local bridges and interfaces on the host 1. Node is registered and given a subnet 2. Pod crated by OpenShift and given IP from Docker bridge 3. Then moved to OVS 4. Container created by Docker engine given IP from Docker bridge 5. Stays connected to lbr0 6. No network duplication – Docker bridge only for IPAM Lbr0 - Docker bridge Br0 - OVS 10.1.0.1 - GW IPAM tun0vxlan0 port1 port2 Container eth0 10.1.0.1 - GW OpenShift schedules pod Docker Schedules pod 10.1.0.3 vlinuxbr vovsbr port3 10.1.0.2 POD PAUSE Contai ner Contai ner localhost veth eth0
- 33. OpenShift SDN –Overlay • Control plane – etcd stores information related to host subnets • Initiated from the node’s OVS via the nodes NIC (vtep – lbr0) • Traffic encapsulated into OVS’s VXLAN interface • When ovs-multitenant driver used – projects can be identified by VNIDs • Adds 50 bytes to the original frame UDP/4789 SRC – 10.15.0.1 DST – 10.15.0.2 14 Bytes 20 Bytes 8 Bytes 8 Bytes Node1 10.1.0.0/24 BR0 (OVS) VTEP Dmz pod 10.1.0.2 Inner pod 10.1.0.3 Node2 10.1.1.0/24 BR0 (OVS) VTEP Dmz pod 10.1.1.2 Inner pod 10.1.1.3 8 Bytes Master etcd Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1
- 34. OpenShift SDN –plugin option1 OVS-Subnet – the original driver • Creates flat network allows all pod to inter- communicate • No network segmentation • Policy applied on the OVS • No significance to project membership Node1 10.1.0.0/24 BR0 (OVS) VTEP Dmz pod 10.1.0.2 Inner pod 10.1.0.3 Node2 10.1.1.0/24 BR0 (OVS) VTEP Dmz pod 10.1.1.2 Inner pod 10.1.1.3 VXLAN Eth0 - 10.15.0.2 Eth0 - 10.15.0.3
- 35. OpenShift SDN –plugin option 2 OVS-Multitenant – • Each projects gets a unique VNID – identifies pods in that project • Default projects – VNID 0 – communicate with all others (Shared services) • Pods’ traffic inspected according to its project membership Node1 10.1.0.0/24 BR0 (OVS) VTEP Dmz pod 10.1.0.2 Inner pod 10.1.0.3 Node2 10.1.1.0/24 BR0 (OVS) VTEP Dmz pod 10.1.1.2 Inner pod 10.1.1.3 VXLAN Project A Vnid 221 Project B vnid 321 Project A Vnid 221 Project B vnid 321 Eth0 - 10.15.0.2 Eth0 - 10.15.0.3
- 36. OpenShift – servicediscovery - alternatives App to App – preferably using Pod-to-Service, avoid Pod-to-Pod Environment variables – • Injected to the pod with connectivity info (user names, service IP..) • For updates, pod recreation is needed • Destination service must first created (or restarted in case they were created before the pod) • Not a real dynamic discovery… DNS – SkyDNZ – serving <cluster>.local suffixes • Split DNS - supports different resolution for internal and external • SkyDNS installed on master and pods are configured by default to use it first • Dynamic - no need to recreate the pods for any service update • Newly created services being detected automatically by the DNS • For direct pod-to-pod connection (no service) – DNS round robin can be used
- 37. VPC OpenShift – Internalcustomer services consumption Yum repos, Docker registry, SMTP, LDAP Leveraging the VPN tunnels from AWS to the customer DMZ 1. The node connects to the requested service proxy in the customer DMZ 2. The proxy initiates the request for the service sources by its own IP – allowed by customer firewall OpenShift node Eth0 - 10.15.0.1 Service proxy Internet Virtual Private GW Customer DMZ Customer GW Customer LAN Docker Reg, Repos, LDAP, SMTP
- 38. Routing and Loadbalancing Requirements Network discovery Alternatives
- 39. 10.1.0.0/16 Routing – alternative1 OpenShift router – • For WEB apps – http/https • Managed by users • Routes created in project level and added to the router • Unless shared, all routers see all routes • For traffic to come in, admin needs to add a DNS record for the router or using wildcard • Default - Haproxy container - listens on the host’s IP and proxies traffic to the pods Master – AWS instance Node2 – AWS instance Node1 – AWS instance Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 Haproxy router https://service.aws.com:8080 Service web-srv1:80 Service web-srv2:80 DNS
- 40. Routing – alternative2 Standalone Load Balancer – • All traffic types • Alternatives are: 1. AWS ELB 2. Dedicated Cluster node 3. Customized Haproxy pod • IP Routing towards the internal cluster network – discussed later AWS ELB 1- service.aws.com:80 10.1.0.0/16 Master – AWS instance Node2 – AWS instance Node1 – AWS instance Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 Service web-srv1:80 Service web-srv2:80 DNS Haproxy pod 3 - service.aws.com:80 Node3 – Haproxy 2- service.aws.com:80
- 41. 10.1.0.0/16 Routing – alternative3 Service external IP– • Managed by Kubernetes Kube- Proxy service on each node • The proxy assigns the IP/port and listens to incoming connections • Redirects traffic to the pods • All types of traffic • Admin should take care of routing traffic towards the node • Iptables-based – all pods should be ready listen • User space - try all pods till it finds Master – AWS instance Node2 – AWS instance Node1 – AWS instance Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 service.aws.com:80 pod web-srv1:80 pod web-srv2:80 DNS Kube-proxy service
- 42. 10.1.0.0/16 OpenShift@AWS – LBrouting to cluster network Concern – network routing towards the cluster network Option 1 – AWS ELB 1. Forwards to the OpenShift node’s IP using port mapping 2. Need application ports coordination - Manageability issues 3. Excessive IPtables for port mapping manipulation – prone to errors 4. Dependency on AWS services Master – AWS instance Node2 – AWS instance Node1 – AWS instance Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 ELB https://service.aws.com:8080 :8080 IPtables Service web-srv1:80 Service web-srv2:80
- 43. 10.1.0.0/16 OpenShift@AWS – LBrouting to the cluster network Concern – network routing towards the cluster network Option 2 – Tunneling 1. Tunnel the external Haproxy node to the cluster via a ramp node 2. Required extra configuration – complexity 3. Extra tunneling – performance issues 4. You need this instance to be continuously up - costly 5. AWS independency Master – AWS instance Node2 – AWS instance Node1 – AWS instance 192.168.0.2/30 Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 Haproxy https://service.aws.com:8080 192.168.0.1/30 Route to 10.1.0.0/16 via 192.168.0.2 Service web-srv1:80 Service web-srv2:80
- 44. 10.1.0.0/16 OpenShift@AWS – LBrouting to the cluster network Concern – network routing towards the cluster network Option 3 – Haproxy move to cluster 1. Put the LB in a LB-only cluster node - disable scheduling 2. Service URL resolved to the node’s IP 3. Full routing knowledge of the cluster 4. Simple and fast – native routing 5. AWS independency 6. You need this instance to be continuously up – costly Master – AWS instance Node2 – AWS instance Haproxy Node – AWS instance Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 https://service.aws.com:8080 Service web-srv1:80 Service web-srv2:80
- 45. 10.1.0.0/16 OpenShift@AWS – LBrouting to the cluster network Concern – network routing towards the cluster network Option 4 – Haproxy container 1. Create Haproxy container 2. Service URL resolved to the container’s IP 3. Full routing knowledge of the cluster 4. AWS independency 5. Use cluster overlay network – native 6. Overlay network - being used anyway Master – AWS instance Node2 – AWS instance Node1 – AWS instance Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 Haproxy pod https://service.aws.com:8080 Service web-srv1:80 Service web-srv2:80 Eth0 – 10.1.0.20
- 46.
- 47. Customer AWS AWS level resourceaccess • Creating VPC, instance, network services, storage services….. • Requires AWS AAA • Managed only by AWS OS level access • SSH or RDP to the instance’s OS….. • Requires OS level AAA or certificates • Managed by the customer ELB, Lambda and application related services are optional. Not considered part of the shared trust model Shared Security responsibility Model
- 48. Intra-pod micro-segmentation • Forsome reason, someone put containers with different sensitivity level within the same pod • OVS uses IP/MAC/OVS port for policy (pod only attributes) • No security policy or network segmentation applied to intra- pod containers • Limited connections or TCP ports blocks - tweaks that won’t help to deal with the newly discovered exploit • “Security Contexts” feature doesn’t apply to intra-pod security but to the pod level • It should be presumed that containers in a pod share the same security level! POD PAUSE Container Container TAP POD PAUSE DMZ DRMS TAP 10.10.10.1 publicly exposed10.10.10.2 SDN Controller localhost localhost Compromised BR-ETH Attacker access the DMZ service’s public IP DMZ service From github’s pod-security-context project page: “We will not design for intra-pod security; we are not currently concerned about isolating containers in the same pod from one another”
- 49. Three options: 1. Separatedclusters – DMZ and SECURE – different networks – implicit network segmentation – expensive but simple for short term 2. Separated nodes same cluster – DMZ nodes and SECURE nodes – applying access control using security groups – communication freely allowed across the cluster – doesn’t give real segmentation with ovs- subnets 3. Using OpenShift’s ovs-multitenant driver – gives micro-segmentation using projects' VNIDs OpenShift SDN – network segmentation
- 50. Option 1 -Cluster level segmentation K8S Secure cluster 10.1.0.0/16 Node2 - internal Node1 - internal Eth0 - 10.15.0.3 App1 10.1.0.1 Eth0 - 10.15.0.2 Master etcd App2 10.1.1.1 Only specific port allowed K8S Exposed cluster 10.1.0.0/16 Node2 - DMZ Node1 - DMZ Eth0 - 10.15.0.3 App1 10.1.0.1 Eth0 - 10.15.0.2 VPC Network Master etcd App2 10.1.1.2 Internet Security group Allows 33111 No shared service discovery knowledge No Network visibility of addresses and ports Lots of barriers and dis-information about the cluster services
- 51. Option 2 -Node segregated – same cluster 1. Exposed app1 has been compromised 2. Cluster service discovery may be queried for various cluster networking knowledge – IPs, ports, services, pods 3. Other pods and services viability, port scanning can be invoked and exploited 4. Other sensitive apps might be harmed The cluster gives the knowledge freedom and tools for further hacking actions K8S cluster 10.1.0.0/16 Node2 - internal Node1 - DMZ Eth0 - 10.15.0.3 App1 10.1.0.1 Eth0 - 10.15.0.2 VPC Network Master etcd Service discovery – full cluster knowledge App2 10.1.1.1 Node2 - internal Eth0 - 10.15.0.3 App3 10.1.1.1 Internet Security group Allows 33111
- 52. OpenShift SDN –network segmentation OVS-Subnet plugin • All projects are labeled with VNID 0 So they allowed to communicate with all other pods and services • No network segmentation • Other filter mechanism required: OVS flows, Iptables, micro- segmentation solutions Node2 10.15.0.3 BR0 (OVS) VTEP Node1 10.15.0.2 BR0 (OVS) VTEP VXLAN dmz inner dmz inner DMZ Service VPC network Inner Service Br0 allows the traffic
- 53. Node1 10.15.0.2 10.1.0.0/24 Node2 10.15.0.3 10.1.0.1/24 OpenShift SDN –network segmentation ovs-multitenant SDN plugin OpenShift default project – VNID 0 – Allows access to/from all All non-default projects – given unique VNID in case they are not joined together Pods – get their network association according to their project membership Pod can access another pod or service only if they belong to the same VNID otherwise OVS blocks them Project A Vnid 221 BR0 (OVS) VTEP Project A Vnid 321 VPC network Project A vnid221 BR0 (OVS) VTEP Project A Vnid 321 VXLAN Dmz pod Inner pod Dmz pod Inner pod Etcd - Project to vnid mapping Network namespace
- 54. Node2 10.15.0.3 Controlled isolation -Egress Router • A privileged pod • Redirects pod’s traffic to a specified external server when it allows connections from specific sources • Can be called via a K8S service • Forwards the traffic outside using its own private IP then it gets NATed by the node • Steps – • Creates MACVLAN interface on the primary node interface • Moves this interface to the egress router pod’s namespace Project A VNID 221 BR0 (OVS) VTEP Project A VNID 321Dmz pod Inner pod Server 234.123.23.2 VPC network internet Customer DMZ Server Egress router pod Eth0.30 10.15.0.20 SRC 10.1.0.2 DST 234.123.23.2 Network namespace SRC 10.15.0.20 DST 234.123.23.2 Etcd - Project to vnid mapping
- 55. Node2 10.15.0.3 Controlled isolation –Gateway pod • Created on the project level • Can be applies only to isolated pods (not default or joined) • Can be used to open specific rules to an isolated app • If pod needs access to specific service belongs to different project, you may add EgressNetworkPolicy to the source pod’s project Project A VNID 221 BR0 (OVS) VTEP Project A VNID 321Dmz pod Inner pod VPC network internet Server HAPROXY/FW vnid0 Eth0.30 10.15.0.20 SRC 10.1.0.2 DST 234.123.23.2 Network namespace SRC 10.15.0.20 DST 234.123.23.2 Etcd - Project to vnid mapping
- 56. 10.1.0.0/16 OpenShift SDN –L3 segmentation use case 1. Secure and DMZ subnets 2. Pods scheduled to multiple hosts and connected to subnets according to their sensitivity level 3. Another layer of segmentation 4. More “cloudy” method as all nodes can be scheduled equally with all types of PODs 5. Currently doesn’t seem to be natively supported 6. Nuage plugin supports this Master Node2 Node1 Eth0 - 10.15.0.2 Eth0 - 10.15.0.3 Eth0 - 10.15.0.1 secure pod1 secure pod2DMZ pod2 Secure Service DMZ Service DMZ pod1 Internet LB 10.1.0.0/24 - Secure 10.1.1.0/24 - DMZ 10.1.0.0/24 - Secure 10.1.1.0/24 - DMZ
- 57. AWS security groupsinspection Concern – Users may attach permissive security groups to instances Q - Security group definition – manual or automatic? A - Proactive way – • Wrapping security checks into continuous integration • Using subnet-level Network ACL for more general deny rules – allowed only to sec admins • Using third party tools: Dome9.. A - Reactive way – Using tools such as aws_recipes and Scout2 (nccgroup) to inspect Lots to be discussed Region AZ AZ VPC Security Group Security Group Routing Table Instance Instance Internet GW VPC router Subnet Virtual Private GW Internet Elastic IP Corporate Instance Eni (interface) Customer GW Eni Instance Subnet Network ACL Admin controlUser control
