Modular PHP Development using CodeIgniter Bonfire
The document provides an overview of a meetup discussing modular PHP development using the CodeIgniter framework and Bonfire, including its MVC architecture and hierarchical model. It explains Bonfire's features such as an administrative dashboard, user authentication, and modular structure, while also detailing the installation and module creation process. Resources for further learning and example modules are also provided for attendees to explore CodeIgniter and Bonfire functionalities.
More Related Content
Similar to Modular PHP Development using CodeIgniter Bonfire
Modular PHP Development using CodeIgniter Bonfire
- 1. Fairfield County PHPMeetup Modular PHP dev using CodeIgniter Bonfire
- 2. About Jeff Fox(@jfox015) • Senior Level Web Developer • Veteran of two browser wars and the dot- com bubble • Fully self taught • Studied Art and Music Production • Baseball enthusiast (ney fanatic)
- 3. Meetup Overview • MVC,CodeIgniter and HMVC in 5 mins. • Intro to Bonfire (more than 5 minutes) • Anatomy of a Bonfire Module • Practical Example • Q&A
- 4. Modular Development Taking HUGEmonolithic applications and breaking them into manageable pieces
- 5. Modular Development "How the heck do we do that?"
- 6. Model, View, Controller Controllers handle requests Models Views present information represent data to the user
- 7. CodeIgniter CodeIgniter • Popular Open Source PHP Framework • Simple MVC Based Architecture • Tons of tools and libraries to utilize in site development workflow • Flexible View system • Known for performance and documentation
- 8. CodeIgniter CodeIgniter • Originally built and released by Ellis Labs, the Expression Engine people • "Reactor" is the community driven build and release initiative • Core team of developers oversee active development and releases • One of the "big three" PHP Frameworks
- 9.
- 10. Hierarchical Model, View, Controller HMVC Triads call on and use other MVC triads to accomplish goals of the application
- 11.
- 12. Bonfire Basics CodeIgniter • OpenSource library built on top of CodeIgniter • HMVC design using Modular Extensions • Pre-built Administrative Dashboard • Rich user authentication workflow • Variety of site admin tools and utilities
- 13. Bonfire Basics CodeIgniter • Dashboardutilizes "contexts" for building admin tools • Database migrations manage upgrades and fallbacks • Custom Model class with built in SQL helper functionality • Several classes of abstract controllers
- 14. Bonfire Basics CodeIgniter • Includesa system of roles to assign to users • Robust permissions allows for precise control over site privileges and user access • Standard system for storing and accessing site settings • Includes a Module Builder wizard to generate fully compatible new modules
- 15. Functional Highlights CodeIgniter • Contextsprovide a loosely coupled way to build Admin tools • Naming conventions prevent hard coding menus • Each module can have its own admin tools and still stay loosely coupled
- 16. Functional Highlights CodeIgniter Themes andTemplates • UI Based on the Twitter Bootstrap libraryBonfire uses a theme and template system for views • Numerous helper functions are available to send data to view classes, select themes, manually set views, set messaging and render the content
- 17. Functional Highlights CodeIgniter Themesand Templates – Examples Template::set('current_url', current_url()); Template::set_message('The comments selected were successfully deleted.', 'success'); Template::set_view('comments/index'); Template::render();
- 18. Functional Highlights CodeIgniter Migrations • Implements the CodeIgninter Migrations class • Adds ability for modules to use migrations • Auto loading of new migrations on app startup (configuable via settings) • Can use DBforge or Codeigniter Database Class and SQL
- 19. Functional Highlights CodeIgniter public functionup() { $this->dbforge- >add_column('comments_threads', array('module' => array('type'=> 'VARCHAR','constraint' => 255,'default' => '')); } public function down() { $this->dbforge- >drop_column("comments_threads","module"); }
- 20. Functional Highlights CodeIgniter Assets Lib •Allows you to add JavaScript, images and CSS automatically in the head and/or footer of the site Assets::add_js($this->load- >view('thread_view_js',array('th read_id'=>$thread_id), true),'in line');
- 21. Functional Highlights CodeIgniter Modular Everything •Allcore Dashboard features are modules • Users • Translate Tool • Activities • Module Builder • Migrations • Logos • Permissions • Emailer • Roles • UI • Settings • Updater • Sysinfo • Database
- 22. Functional Highlights CodeIgniter Easy Install Twostep install Like Wordpress
- 23. Bonfire Team CodeIgniter Lonnie Ezell Nuno Costa Project Founder Ben Evans Icehawg Sean Downey and many more on Github.com Shawn Crigger
- 24. Anatomy of a BonfireModule
- 25. General Structure CodeIgniter • Allthird party and custom modules are stored in the "modules" folder in the bonfire directory. • Core modules live in the "core_modules" folder in the application directory.
- 26. General Structure CodeIgniter • Bonfire Modules are like little stand-alone CodeIgniter apps • Modules follow the context naming convention system to allow access to their controllers throughout the site • Can be 100% standalone or work with other modules • Optimally can be dropped into other apps
- 27. Naming Conventions CodeIgniter Controllers •Public accessible, add controller with a name that matches the modules folder name • Admin Dashboard (Also called the Springboard) Controllers, add a controller that matches the context name
- 28. Naming Conventions CodeIgniter Auto-Resolving Views •For public views, and index.php to the modules "Views" folder • Admin views, add a folder for the matching context in the "Views" folder with an index.php file in it.
- 29. Naming Conventions CodeIgniter Manually ResolvingViews • In the controller, before calling Template::render(), add a line to set the view using Template::set_view('view'); • Any view from any loaded module can be used simply by specifying the module path and view name
- 30. Config CodeIgniter • config.php containsa simple array that identifies the module to the application and contain it's meta information • Config folder may contain other files used to store information about the app • Custom routes.php files can be used to add additional levels of URL->controller routing
- 31. Controllers CodeIgniter • Contains allcontrollers used by the modules • Should extend one of the four main Bonfire controller types: o Base_Controller o Front_Controller o Authenticated_Controller o Admin_Controller
- 32. Views CodeIgniter • Adding anindex.php file to the views folder makes it publically accessible • Adding folders named for supported admin contexts with index.php files makes them accessible from admin menus • No limit to number of view files there can be, how they're organized outside context rules or how they're called
- 33. Misc CodeIgniter • Models followgeneral CI model rules. Should extend BF_Model to gain Bonfire helper functionality. • Migrations are used to install DB support and handle changes • Language files support translations • Can add helpers, libraries and assets as well
- 34.
- 35.
- 36.
- 37. Resources CodeIgniter •Bonfire Learning Center http://www. http://cibonfire.com/docs/guides/ • Github Repository https://github.com/ci- bonfire/Bonfire
- 38. Resources CodeIgniter •Tutorials on MVC, HMVC, CodeIgniter at http://net.tutsplus.com/ See MVC for Noobs, CodeIgniter from Scratch, HMVC: an Introduction and Application • OOWP For Developers Tutorials http://www.aeoliandigital.com/archi ves/category/oowp
- 39. Resources CodeIgniter ExampleModules: • News: https://github.com/jfox015/Bonfire- News • Comments: https://github.com/jfox015/Bonfire- Comments
