- 1. Parallel processing with Spring Batch Lessons learned
- 2. Morten Andersen-Gott • Manager at Accenture Norway • 30 years old • Been using Spring Batch since 1.0M2 (2007) • Member of JavaZone program committee – http://tinyurl.com/javaever – http://tinyurl.com/thestreaming – http://tinyurl.com/ladyjava mortenag www.github.com/magott www.andersen-gott.com
- 3. A BoF focusingon the problems • Functional background for the batch • Short introduction to Spring Batch • Even shorter on Hibernate • The problems • The problems • The problems
- 4. Norwegian Public Service Pension Fund (SPK) • Norway’s main provider of public occupational pensions • Also provide housing loans and insurance schemes • Membership of the Norwegian Public Service Pension Fund is obligatory for government employees • Stats – 950,000 members across 1600 organisations – Approx 138,000 receive a retirement pension – Approx 58,000 receive a disability pension – 950,000 members have total accrued pension entitlements in the Norwegian Public Service Pension Fund of 339 billion kroner.
- 5. Background • Every yearthe parliament sets the basic amount of the national insurance • This amount is a constant used in calculation of all benefits • When the basic amount is changed, all benefits must be recalculated • It’s more complex than a constant in an algorithm – Rules are result of political games the last 50 years – Complex rules – Lots of exemptions
- 6. Execution time requirements •SPK’s recalculation batch must run – After the basic amount is set – After the Labour and Welfare Administration has done it’s calculation – Before the pensions are due next month • Window of 1 week – Will ideally only run during weekends – Can not run while case workers are doing their job
- 7. Spring Batch • Frameworkfor developing batch applications • Implements batch semantics – Steps, Chunks, Stop, Restart, Skips, Retries – Partitioning, Multithreading, Parallel steps
- 8.
- 9. The components • ItemReader – read() returns one row at the time – Step is completed once read()returns null • ItemProcessor – process(item) item is return value from read() – Business logic goes here – Items can be filtered out by returning null • ItemWriter – Write(list) list of items returned from process()
- 10. The code <job id=”foo”> <step id="fileImport"> <tasklet> <chunk commit-interval="10" reader=“reader" processor=“processor" writer=“writer“/> </tasklet> </step> </job> <bean id=“reader" class="..."> <bean id=“processor" class="..."> <bean id=“writer" class="...">
- 11. Chunk • A chunkis a unit of work – Executes within a transaction – Size is defined by number of items read • A step is divided into chunks by the framework • When x is the chunk size – read() is called x times – process() is called x times – write is called once with a list where list.size()==x (minus filtered items)
- 12.
- 13. Multi-threaded step Id Name 1 Paul 2 John 3 Lisa Execution Reader Step 4 Simon Processor T1..* 5 Rick Writer 6 Julia 7 Olivia 8 Scott 9 Martin
- 14. Partitioned Step Id Name Execution Reader Step 1 Paul T1 Processor 2 John Writer 3 Lisa Execution Reader Step 4 Simon Processor T2 5 Rick Writer 6 Julia Execution 7 Olivia Reader Step Processor T3 8 Scott Writer 9 Martin
- 15. Hibernate 101 • Proxy •Session cache • Flushing – Queries – Commit
- 16.
- 17. - Stored procedure Step1 Populate staging table - Read from staging - Fetch additional data Step 2 Rules - Call out to rules engine engine - Store result as pending pensions - Loop through pending Step 3 pensions and activate - Create manual tasks Step 4 for failed items
- 18. Staging table • Abatch processing pattern • A simple table with a identity column, functional key and processing status • Restart is easy – Select soc_sec from staging where processed=false • An easy way to get parallel processing capabilities
- 19.
- 20. Reader Updates family status Processor Step 2 ILog Sybase Writer
- 21. Hibernate in thereader • Using a separate statefull session in reader – Not bound to active transaction – Is never flushed – clear() is called before commit • Entities are written to database using a (different) transaction bound session – Used by processor and writer
- 23.
- 24. What happened? org.hibernate.HibernateException: Illegal attempt to associate a collection with two open sessions
- 25. Why • Family.errors andFamily.persons are attached to reader’s session • Attempting to attach them to transaction bound session • Hibernate will have non of that!
- 26.
- 27.
- 28. Hibernate in thereader (Second attempt) • Let’s try stateless session • Default behavior in Spring Batch’s Hibernate ItemReaders – useSateless=”true” • LEFT JOIN FETCH for eager loading collections – Avoiding LazyLoadingExceptions
- 29. Hibernate in thereader (Second attempt)
- 30.
- 31. What happened? • org.hibernate.HibernateException:cannot simultaneously fetch multiple bags
- 32. Why • Hibernate isunable to resolve the Cartesian product – Throws exception to avoid duplicates
- 33. You are usingit wrong!
- 34. Curing the Problems? you are using it wrong syndrome
- 35. Hibernate in thereader (The third attempt) • Examine the object graph • Replace List with Set – Only one eagerly loaded collection may be of type list List • This works… – ..for a while – We’ll revisit Hibernate later…
- 36. Exception resilience • Newdemands sneak in – The batch should not abort • Not under any circumstance • The batch should deal with – Missing or functionally corrupt data – Programming errors – ...
- 37. Pseudo code try{ //do data and business operations }catch(Exception e){ //Add error to staging & continue family.addError(createError(e)); }
- 38.
- 39. Overzealous exception handling anassertion failure occurred (this may indicate a bug in Hibernate, but is more likely due to unsafe use of the session)
- 40. Overzealous exception handeling The solution • Some exception MUST result in a rollback – Ex. StaleStateException • Configure the framework to do retry/skip for these • Only catch exceptions you know you can handle in a meaningful way – Nothing new here – Do not succumb to crazy requirements
- 41. Time to turnon parallelization • We chose partitioned over mutli-threaded step – No need for a thread safe reader • Step scope • Each partition get a new instance of reader – Page lock contentions are less likely • Row 1 in partition 1 not adjacent to row 1 in partition 2
- 42. Deadlocks • Legacy databaseusing page locking • Normalized database • Relevant data for one person is spread across a number of tables • Different threads will access same data pages • Deadlocks will occur
- 43. Page locking ID NAME 1 Paul T1 2 John T2 waiting 3 Simon 4 Scott T1 waiting 5 Lisa T2 6 Jack 7 Nina 8 Linda T3
- 44.
- 45. Retry to therescue <step id=”step2"> <tasklet> <chunk reader="reader" processor="processor" writer="writer" commit-interval="10" retry-limit="10"> <retryable-exception-classes> <include class=”…DeadlockLoserDataAccessException"/> </retryable-exception-classes> </chunk> </tasklet> </step>
- 46.
- 47.
- 57.
- 58.
- 66.
- 67. What do wedo?
- 68. What we shouldhave done weeks ago
- 69. We ditch Hibernate …well,almost anyway
- 70. Removing Hibernate from reader • ItemReader is re-configured to use JDBC • Fetches primary key from family staging table • ItemProcesser fetches staging object graph – Uses primary key to fetch graph with hibernate • Primary keys are immutable and stateless
- 73. End result • Performance requirement was 48 hrs • Completed in 16 hrs • Used 12 threads • C-version used 1 thread and ran for 1 week – Stopped each morning, started each evening • A batch that scales with the infrastructure – Number of threads is configurable in .properties
- 74. What we wouldhave done differently • Switched from partioned to multi-threaded step – All work is shared among threads – All threads will run until batch completes – Avoid idle threads towards the end – With partitioning some partitions finished well before others
- 75. Recommendations • Do notuse Hibernate in the ItemReader • Test parallelization early • Monitor your SQLs – Frequently called – Long running • Become friends with your DBA • There is no reason to let Java be the bottle neck – Increase thread count until DB becomes the bottle neck
- 76.
- 77. Pro tip: @BatchSize •If one lazily loaded entity is fetched, they are all fetched – in one query
Editor's Notes
- #4 trials and tribulationsfairy tale
- #5 Offers a lot of different benefits for employees or former employees of the public sector in NorwayPlays a major part in the personal economy for a lot of Norwegian citizens
- #6 To reflect changes in consumer price indexBenefits
- #7 Labour and Wellfare Administration provides the minimum pensions for all Norwegian citizensWe rely on the calculations from the Wellfare Administration in our batch
- #9 2 loopsOuter: Loops while read returns dataInner: Loops over read+process according to commit-interval
- #15 Data is partitioned before step executesThreads are processing isolated data setsExamples of partitioning strategiesOne file per partitionPartitioning a tablePartition 1: Row 1 – Row 1000Partition 2: Row 1001 – Row 2000Partition 3: Row 2001 – Row 3000
- #48 Indicates that session contained stale dataThrown when a version number or timestamp check failsAlso occurs if we try delete or update a row that does not existStarted doing the numbers, how much can we do within 48 hours with a single thread?Weknewthattwothreadswould never accessthe same row. Same page, sure, but never same row.
- #62 The ItemReader is forward-onlyWe can’t roll back a cursor next()Spring batch stores all read items in a retry cache until transaction is committedUses the cache for retries
- #68 Hibernatethrows an exceptionwhenrealitydoes not match itsexpectations
