Recursion Lecture in Java

Recursion Lecture in Java

• 1.
  Recursion lecture inJava Recursively breaking down a problem into two or more sub-problems of the same (or related) type, until these become simple enough to be solved directly. The solutions to the sub-problems are then combined to give a solution to the original problem. Top-Down Design Cleaning apartment/house. Example Divide and Conquer Algorithm Many divide and conquer type algorithms can be implemented as recursive functions. Condition that leads to a recursive method returning without making another recursive call. Stops the recursion. Solution to this case is simple enough to solve directly. Base case. Calls itself to solve smaller sub-problems. May combine the results of the sub-problems. Properties of recursive functions Recursive methods /** * This is the recursive form of arithmetic series * x = x + (x-1) + (x-2) + .. + 0 */ public class ArthmeticSeries { public static void main(String[] args) { int sum = arthmeticSeries(2); System.out.println(sum); } private static int arthmeticSeries(int x) { //base case. if (x == 0) return 0; Example: Arithmetic Series
• 2.
  //base case. if (x== 0) return 0; //recursive case. return x + arthmeticSeries(x - 1); } } Example: cafeteria plates. A stack is a FIFO data structure. Each method call produces a stack frame (like a plate). Information about the method. Method arguments. Information on how to return to the caller. Each frame consists of: What does recursion look like on the call stack? The Fibonacci sequence a(1), a(2), a(3), ..., a(n), ... is defined by a(1) =1 a(2) = 1 a(n) = a(n-1) + a(n-2) , for all n > 2 This generates the sequence: 1, 1, 2, 3, 5, 8, 13, 21, ... fibonacci(7) == 13 public class Fibonacci { public static void main(String[] args) { int num = fib(7); System.out.println(num); } private static int fib(int x) { if (x == 0) return 0; if (x == 1) return 1; Example: Fibonacci sequence
• 3.
  return 0; if (x== 1) return 1; return fib(x - 1) + fib(x - 2); } } public class BinarySearch { public static void main(String[] args) { int myArray[] = {41, 62, 77, 80, 85, 92, 104, 211, 400}; int pos = binsearch(myArray, 0, myArray.length, 62); System.out.println(pos); pos = binsearch(myArray, 0, myArray.length, 97); System.out.println(pos); } private static int binsearch(int arr[], int start, int end, int val) { if ( start > end ) //if empty. return -1; //not found. int mid = (start + end) / 2; if ( arr[ mid ] == val ) return mid; //found it! else if ( arr[ mid ] < val ) return binsearch(arr, mid + 1, end, val); else //arr[ mid ] > val return binsearch(arr, start, mid - 1, val); } } ex: 41 62 77 80 85 92 104 211 400 - search for 62 - check index 4 ((0+8)/2) - (0+3)/2 - report found - search for 97 - 97 > 85 - (5+8)/2 = 6 - 97 < 104 - (5+5)/2 = 5 - 97 > 92 Example: Binary Search
• 4.
  - (5+8)/2 =6 - 97 < 104 - (5+5)/2 = 5 - 97 > 92 - use low and high index values to find that there are no more values to search Consider the sorting problem. That is, given a list of comparable items (say an array of {bf int}s) in arbitrary order, rearrange that list of items so that they are in {it non-decreasing} order. For example, say you have an array of {bf int}s: $langle 38, 27, 43, 3, 9, 82, 10 rangle$. A sorted version of this array would be $langle 3, 9, 10, 27, 38, 43, 82 rangle$. Next, consider an efficient, divide and conquer algorithm that can be used to {it recursively} solve the sorting problem as follows: begin{enumerate} item Divide the unsorted list into two sublists of about half the size. item Divide each of the two sublists recursively until we have list sizes of length $1$, in which case the list itself is returned (after all, a list containing only $1$ element is always considered sorted!). item Merge the two sublists back into one sorted list. end{enumerate} Suppose now that you had the following function available to you: begin{lstlisting}{} void merge(Item arr[], const int& left, const int& right, const int& pivot); end{lstlisting} that combines two {bf sorted} sub-arrays of {tt arr} (i.e., the inclusive intervals [{tt left}, {tt pivot}] and [{tt pivot}$+1$, {tt right}]) to a underline{single} {bf sorted} array. The result of this {it combined}, sorted array is stored back into {tt arr} to form a single, sorted array whose valid elements are contained in the interval [{tt left}, {tt right}]. {tt Item} refers to a type (possibly through use of a {bf typedef}) whose members are comparable (e.g., {bf int}). /* * 'a' is an array of 'Items' whose valid elements are between 'start' and 'end', * inclusively. 'mid' is the position in 'a' in which to divide the array. */ void mergesort(Item a[], const int& start, const int& end, const int& mid) { if ( start >= end ) //the array is either empty or contains a single element. return; //sorting problem already solved. Nothing to do. Example: Mergesort
• 5.
  if ( start>= end ) //the array is either empty or contains a single element. return; //sorting problem already solved. Nothing to do. //sort the left portion of the array. mergesort(a, start, mid, (start + mid) / 2); //sort the right portion of the array mergesort(a, mid + 1, end, (mid + 1 + end) / 2); //combined the two sorted array portions in a single sorted array. merge(a, start, end, mid); }
