- 1. IOT Using Arduino By Surya TejaSwamy…. Certified Labview Associate Developer KLEF Deemed to be University
- 2. Arduino • Arduino isan open source, computer hardware and software company, project, and user community that designs and manufactures microcontroller kits for building digital devices and interactive objects that can sense and control objects in the physical world.
- 3. IOT The Internet ofthings (IoT) is the inter-networking of physical devices, vehicles (also referred to as "connected devices" and "smart devices"), buildings, and other items - embedded with electronics, software, sensors, actuators. Network connectivity that enable these objects to collect and exchange data. In 2013 the Global Standards Initiative on Internet of Things (IoT-GSI) defined the IoT as "the infrastructure of the information society. The IoT allows objects to be sensed or controlled remotely across existing network infrastructure, creating opportunities for more direct integration of the physical world into computer-based systems, and resulting in improved efficiency, accuracy and economic benefit in addition to reduced human intervention.
- 4. Cont … When IoTis augmented with sensors and actuators, the technology becomes an instance of the more general class of cyber-physical systems, which also encompasses technologies such as smart grids, smart homes, intelligent transportation and smart cities. Each thing is uniquely identifiable through its embedded computing system but is able to interoperate within the existing Internet infrastructure. Experts estimate that the IoT will consist of almost 50 billion objects by 2020.
- 5. Micro Controller • ATmega8is a 8-bit microcontroller based on the AVR RISC architecture • By executing powerful instructions in a single clock cycle, the ATmega8 achieves throughput approaching 1 MIPS per MHz
- 6. Cont.... • In orderto maximize performance and parallelism, the AVR uses a Harvard architecture- which separates memories and buses for program and data • Instruction in program memory are executed with single level pipelining • This concept enables instructions to be executed in every clock cycle
- 7. FEATURES High-performance 8bit Microcontroller Up to 16 MIPS Throughput at 16 MHz 32 x 8 General Purpose Working Registers Six ADC channels in PDIP package Internal Calibrated Oscillator
- 8. List of Sensor’s IR Sensor DHTlevel – Temperature Sensor HC 05 – Bluetooth Device Sensor LDR – Light Dependent Resistor ULTRASONIC Sensor ESP8266 – Internet Sensor
- 9.
- 10. WORKING • IR sensorworks on the principle of emitting IR rays and receiving the reflected ray by a receiver (Photo Diode). • IR source (LED) is used in forward bias. • IR Receiver (Photodiode) is used in reverse bias.
- 11. VOLTAGE COMPARATOR • A Comparatoris a device which compares two voltages or currents and switches its output to indicate which is larger. • Comparator is an Op-amp.
- 12.
- 13.
- 14. Program on IRSensor
- 15.
- 16.
- 17.
- 18. Analog to Digital(intensityof light)
