scala-gopher: async implementation of CSP for scala

https://github.com/rssh/scala-gopher
.
Ruslan Shevchenko <ruslan@shevchenko.kiev.ua>
@rssh1

• CSP = Communicating Sequential Processes.
• Tony Hoar.
• classical paper from 1978
• book: http://www.usingcsp.com/ (1985)
• Languages
• Occam (1983) for specialized hardware [transputers]
• Go (2007) - got popular:
• Rob Pike (C, Plan9)
• in Google

Write (“blocked”) Read (“blocked”)
Channel (buffered)
Channel (unbuffered)
Computation blocks
are connected
by channels
// in INMOS transputers - physically

❖ Simple mental model
❖ Ability to “coordinate” between input/output sinks
go func(){
for { select {
case x <- inX:
var y <- inY
if (x == y) {
fmt.fprintf(“Bingo!”)
}
case q <- inQuit:
break;
} }()
}
// Go

❖ Simple mental model
❖ Ability to “coordinate” between import
go func(){
for { select {
case x <- inX:
var y <- inY
if (x == y) {
}
case q <- inQuit:
break;
} }()
}
waits
// Go

scala-gopher:
• Not ‘emulation of go in scala’ but
• ‘CSP constructs in scala-way'
• Asynchronous
• build on top of Akka and SIP 22 - async
// ‘block’ is not block
// ‘wait’ is not wait

go func(){
for { select {
case x <- inX:
var y <- inY
if (x == y) {
}
case q <- inQuit:
break;
} }()
}
select.forever {
case x: inX.read =>
val y = inY.read
if (x == y) {
Console.println(“Bingo!”)
}
case q: inQuit.read =>
currentFlow.exit(())
}
Go Scala

go func(){
for { select {
case x <- inX:
var y <- inY
if (x == y) {
}
case q <- inQuit:
break;
} }()
}
select.forever {
case x: inX.read =>
val y = inY.read
if (x == y) {
}
}
Go Scala
3 constructions (common combination)

select.forever {
case x: inX.read =>
val y = inY.read
if (x == y) {
}
}
// select.forever: basic construct
Scala

select.forever {
case x: String if (x==(inX|1inX2).read) =>
val y = inY.read
if (x == y) {
}
case q: Boolean if (q==inQuit.read) =>
}
Scala

Unblocked:
selector:
forever: apply(choice: PartialFunction[Any,Unit]): Future[Unit]
once: apply[T](choice: PartialFunction[Any,T]): Future[T]
go[T]: Future[T]
“Blocked”: (must be inside ‘go’ or ‘async’ ):
forever: foreach(choice: PartialFunction[Any,Unit]): Unit
once: foreach[T](choice: PartialFunction[Any,T]): T

Inside Partial Function:
❖ reading from Input[A] and do something
❖ Channel[A], Future[A], user input
❖ writing to Output[A] and do something
❖ Channel[A], user output
❖ do something on idle.
“ do something” wrapped in async block,
so we can ‘block’ there

Input[A]:
❖ unblocked:
❖ aread, atake, aforeach
❖ ‘blocked:’
❖ read, take, foreach ….
❖ composition
❖ map, filter, zip, or, dup
❖ construction
open: ‘wait’
closed: throw exception on
reading after ‘last’ element
❖ channel, future, collection, own implementation

Output[A]:
❖ unblocked:
❖ awrite, awriteAll,
❖ ‘blocked:’
❖ write, writeAll ….
❖ composition
❖ — (?)
❖ construction
open: ‘wait’
closed: throw exception on
writing element
❖ channel, actor, own implementation

Channel[A]:
❖ Input[A] + Output[A]
❖ garbage-collected.
❖ gopherApi.makeChannel
❖ can be buffered

Timeouts:
val (inReady, inTimeouts) = in.withInputTimeouts(30 seconds)
for(s <- selector.forever) {
case a:inReady.read =>
Console.println(s“received ${a}”)
case t:inTimeouts.read =>
Console.println(“timeout occurred”)
}
Input => withInputTimeouts
Output => withOutputTimeouts

go[T](T :=> Future[T])
❖ async + defer/recover
❖ defer(callback: =>Unit): Unit
[finally]
❖ recover(handler: PartialFunction[Throwable,T]):Boolean
go {
val source = fetchSource(url)
val csv = parseCsv(source)
val svFile = new FileOutputStream(csv.name, append=true)
defer{
val r = recover{
case FileNotFoundException => signal(“file not found”)
}
if (!r) svFile.close()
}
for(s <- csv.data) svFile.print(s)
}
[catch]

go[T](T :=> Future[T])
go {
val source = fetchSource(url)
val csv = parseCsv(source)
val svFile = new FileOutputStream(csv.name, append=true)
defer{
val r = recover{
case FileNotFoundException => signal(“file not found”)
}
if (!r) svFile.close()
}
for(s <- csv.data) svFile.print(s)
}

goScope[T](T :=> T)
goScope {
val in = new FileInputStream(inf)
defer { in.close() }
val out = new FileOutputStream(outf)
defer{ out.close() }
out.getChannel().transferFrom(in.getChannel,
0,Long.MaxValue)
}

❖ All “essential” functionality of CSP model
❖ Fully asynchronous implementation
❖ In normal language, with generic, typing, ..
❖ …. more: scala is object-oriented.

Reusable block:
❖ Set of input and output ports.
❖ Some internal state
❖ Functionality for signal transformations
Transputer:

trait Bingo extends SelectTransputer {
val inX = InPort[Int]()
val inY = InPort[Int]()
val out = OutPort[Boolean]()
loop {
case x: inX.read =>
val y = inY.read
Console.println(s"Bingo checker, received ${x}, ${y}”)
out.write(x==y)
}
}

trait Acceptor extends SelectTransputer {
val inA = InPort[Boolean]()
@volatile var (nBingos, nPairs) = (0,0)
loop {
case x: inA.read =>
Console.println(s"acceptor: ${nPairs} ${nBingos} ${x}")
if (x) {
nBingos += 1
}
nPairs += 1
}
}

val inX = gopherApi.makeChannel[Int]()
val inY = gopherApi.makeChannel[Int]()
val bingo = gopherApi.makeTransputer[Bingo]
val acceptor = gopherApi.makeTransputer[Acceptor]
bingo.inX connect inX
bingo.inY connect inY
bingo.out connect acceptor.inA
(bingo + acceptor).start()

Transputers
❖ Like ‘actors’ but works with ports
❖ We can ‘wait’ inside
❖ Connected via channels.
❖ Restartable
// in remind of INMOS transputers

Select
select.foreach {
……………
}

Replicate
Mapping
gopherApi.replicate[X](5)

Replicate
gopherApi.replicate[X](5).in.distribute(_ % 10)
Mapping
Element e from in will be directed to (e%10) instance of X

❖ Select: [handle one transformation]
❖ Parallel[ transputers are run in parallel]
❖ Replicated
❖ [ run in parallel N instances.]
❖ [ custom logic for port shuffling ]
Transputer Supervisor => ActorSystem
Transputers

Implementation
sealed trait Continuated[T]
case class ContRead[A,T]( callback , input, flow) extends Continuated[T]
case class ContWrite[A,T]( callback , output, flow) ..
case class ContSkip[T](callback, flow) …
case class Done[T]( value , flow) ……..
case object Never ……….
// simular to Iteratee

Implementation
case class ContRead[A,T]( callback , input, flow) extends Continuated[T]

Implementation
case class ContRead[A,T](
function: ContRead[A,B] => Option[
ContRead.In[A] =>
Future[Continuated[T]]
] ,
input,
flow) extends Continuated[T]

Implementation
case class ContRead[A,T](
function: ContRead[A,B] => Option[
ContRead.In[A] =>
Future[Continuated[T]]
] ,
input,
flow) extends Continuated[T]
Value, Skip, Failure
Read as Protocol:
(check, if available, read, return next step)

Implementation
Flow
Dispatch Actor
wait in channel read/write
Flow
wait in select

scala-gopher
❖ CSP within scala ecosystem
❖ Channels complementary to RxStreams
❖ ‘async rw/async callback’
❖ Transducers complementary to Actors
❖ ‘transform streams/event reactions’
❖ Can be used together.

scala-gopher
❖ https://github.com/rssh/scala-gopher
❖ Ruslan Shevchenko
❖ @rssh1
❖ Questions ?
