Algorithms 1

PRESENTED TO :-
•

Madam Huma

1

Presented By:-

Muhammad Uzair Rasheed
2009-CPE-03
UCE&T BZU MULTAN

2

The Objective of Today’s Presentation

To become familiar with the concept of
algorithms:

– What they are?
– What is their use?
– What do they consist of?
– What are the techniques used for
representing them?
– How do we can analyze them?
3

al.go.rithm
steps
sequence
Sequence of steps
that can be taken to solve a given problem

4

Solving Problems (1)
When faced with a problem:
1. We first clearly define the problem
2. Think of possible solutions
3. Select the one that we think is the best
under the prevailing circumstances
4. And then apply that solution
5. If the solution woks as desired, fine; else
we go back to step 2 5

• It is quite common to first solve a problem
for a particular case
• Then for another
• And, possibly another
• And watch for patterns and trends that
emerge
• And to use the knowledge form those
patterns and trends in coming up with a
general solution 6

• It helps if we have experienced that problem
or similar ones before

• Generally, there are many ways of solving a
given problem; the best problem-solvers
come-up with the most appropriate solution
more often than not!

• The process that can be used to solve a
problem is termed as the “algorithm” 7

Examples
• Addition
• Conversion from decimal to binary
• The process of boiling an egg
• The process of mailing a letter
• Sorting
• Searching

8

Let us write down the algorithm for
a problem that is familiar to us

Converting a decimal number into binary

9

Convert 75 to Binary
2 75 remainder
2 37 1
2 18 1
2 9 0
2 4 1
2 2 0
2 1 0
0 1

1001011 10

Algorithm for Decimal-to-Binary Conversion

1. Write the decimal number

2. Divide by 2; write quotient and remainder

3. Repeat step 2 on the quotient; keep on
repeating until the quotient becomes zero

4. Write all remainder digits in the reverse order
(last remainder first) to form the final result
11

Three Requirements:
1. Sequence is:
a. Precise
b. Consists of a limited number of steps

2. Each step is:
a. Unambiguous
b. Executable

3. The sequence of steps terminates in
the form of a solution 12

Why Algorithms are Useful?
• Once we find an algorithm for solving a
problem, we do not need to re-discover it the
next time we are faced with that problem

• Once an algorithm is known, the task of
solving the problem reduces to following
(almost blindly and without thinking) the
instructions precisely

• All the knowledge required for solving the
problem is present in the algorithm 13

Why Write an Algorithm Down?
• For your own use in the future, so that you
don’t have spend the time for rethinking it

• Written form is easier to modify and improve

• Makes it easy when explaining the process
to others

14

Analysis of Algorithms
• Analysis in the context of algorithms is concerned with
predicting the resources that re requires:
– Computational time
– Memory
– Bandwidth
– Logic functions

• However, Time – generally measured in terms of the
number of steps required to execute an algorithm - is
the resource of most interest

• By analyzing several candidate algorithms, the most
efficient one(s) can be identified 15

A Selection of Algorithmic
Application Areas
• Search
• Sort
• Cryptography
• Numeric
• Graphical
• Quantum computing

16

We’ll now talk about the various
ways of representing algorithms.

But, before we do that please allow
me to say a few words about …

17

Syntax & Semantics
An algo. is “correct” if its: WARNINGS:
– Semantics are correct
1. An algo. can be
– Syntax is correct syntactically correct,
yet semantically
Semantics: incorrect – very
The concept embedded in dangerous situation!
an algorithm (the soul!)
2. Syntactic
Syntax: correctness is easier
The actual representation to check as
of an algorithm (the body!) compared with 18

Now onto Algorithm Representation
• We have said enough about algorithms – their
definition, their types, etc.

• But, how do we actually represent them?

• Generally, SW developers represent them in
one of three forms:
– Pseudo code
– Flowcharts
– Actual code 19

HOW TO WRITE AN ALGORITHM

• Part-1:-
• NAME OF ALGORITHM(NAME OF
VARIABLES USED)
• BRIEF DISCRIPTION ABOUT VARIABLES
USED IN SIMPLE ENGLISH
• Part-2:-
• Series of steps to solve a problem

20

OPERATIONS THAT CAN BE PERFORMED

• TRAVERSING

• INSERTION

• DELETION

• SORTING

• MERGING
21

Types of sorting
• Bubble sorting.

• Selection sorting.

• Insertion sorting.

• Merge sorting.
22

Method of Bubble sorting
• To sort data in an array of n elements,
n-1 iterations are required.

• There are following steps explain
sorting of data in ascending order using
bubble sort method:
23

• In first Iteration, the largest value
moves to the last position in the array.
• In the second iteration the above
process is repeated and the second
largest value moves to the second last
position and so on.
• In n-1 iteration, the data is arranged in
ascending order.
24
