![Memory Monitoring
• pmap -sax $pid
> To understand the details of memory consumption of a
process
# pmap -sax 20787
20787: /export/home/postgres/pgsql/bin/postgres
Address Kbytes RSS Anon Locked Pgsz Mode Mapped File
0000000000400000 4 4 - - 4K r-x-- postgres
0000000000401000 340 - - - - r-x-- postgres
..
0000000000C80000 12 12 12 - 4K rw--- [ heap ]
0000000000C83000 4 - - - - rw--- [ heap ]
0000000000C84000 4 4 4 - 4K rw--- [ heap ]
FFFFFD7F00000000 120832 120832 120832 120832 2M rwxsR [ ism shmid=0x36 ]
FFFFFD7F07600000 3115440 3115440 3115440 3115440 4K rwxsR [ ism shmid=0x36 ]
FFFFFD7FFF010000 64 8 - - - rwx-- [ anon ]
FFFFFD7FFF040000 4 4 - - - rwx-- [ anon ]
FFFFFD7FFF050000 16 16 - - 4K r-x-- en_US.ISO8859-1.so.3
...
FFFFFD7FFFDF7000 20 20 20 - 4K rw--- [ stack ]
FFFFFD7FFFDFC000 12 12 - - - rw--- [ stack ]
FFFFFD7FFFDFF000 4 4 4 - 4K rw--- [ stack ]
---------------- ---------- ---------- ---------- ----------
total Kb 3247600 3245420 3239316 3236272](https://image.slidesharecdn.com/postgresqlconferenceeast2008-bestpracticesofpostgresqlwithsolaris-160110071313/85/Best-Practices-with-PostgreSQL-on-Solaris-23-320.jpg)
![Basic Locks Monitoring
• Dtrace Scripts based on postgresql provider
> PostgreSQL level locking profile
#!/usr/sbin/dtrace -qs
dtrace:::BEGIN
{ lckmode[0] = "Exclusive";
lckmode[1] = "Shared"; }
postgresql*:::lwlock-startwait
{ self->ts[arg0]=timestamp;
@count[arg0, lckmode[arg1]] = count(); }
postgresql*:::lwlock-endwait
/self->ts[arg0]/
{ @time[arg0 ,lckmode[arg1]] = sum (timestamp - self->ts[arg0]);
self->ts[arg0]=0; }
dtrace:::END
{ printf("n%20s %15s %15sn", "Lock Id", "Mode", "Count");
printa("%20d %15s %@15dn",@count);
printf("n%20s %15s %20sn", "Lock Id","Mode", "Combined Time (ns)");
printa("%20d %15s %@20dn",@time); }
tick-10sec
{ exit(0);}
# ./lwlock_wait.d](https://image.slidesharecdn.com/postgresqlconferenceeast2008-bestpracticesofpostgresqlwithsolaris-160110071313/85/Best-Practices-with-PostgreSQL-on-Solaris-31-320.jpg)
![Memory Monitoring
• pmap -sax $pid
> To understand the details of memory consumption of a
process
# pmap -sax 20787
20787: /export/home/postgres/pgsql/bin/postgres
Address Kbytes RSS Anon Locked Pgsz Mode Mapped File
0000000000400000 4 4 - - 4K r-x-- postgres
0000000000401000 340 - - - - r-x-- postgres
..
0000000000C80000 12 12 12 - 4K rw--- [ heap ]
0000000000C83000 4 - - - - rw--- [ heap ]
0000000000C84000 4 4 4 - 4K rw--- [ heap ]
FFFFFD7F00000000 120832 120832 120832 120832 2M rwxsR [ ism shmid=0x36 ]
FFFFFD7F07600000 3115440 3115440 3115440 3115440 4K rwxsR [ ism shmid=0x36 ]
FFFFFD7FFF010000 64 8 - - - rwx-- [ anon ]
FFFFFD7FFF040000 4 4 - - - rwx-- [ anon ]
FFFFFD7FFF050000 16 16 - - 4K r-x-- en_US.ISO8859-1.so.3
...
FFFFFD7FFFDF7000 20 20 20 - 4K rw--- [ stack ]
FFFFFD7FFFDFC000 12 12 - - - rw--- [ stack ]
FFFFFD7FFFDFF000 4 4 4 - 4K rw--- [ stack ]
---------------- ---------- ---------- ---------- ----------
total Kb 3247600 3245420 3239316 3236272](https://image.slidesharecdn.com/postgresqlconferenceeast2008-bestpracticesofpostgresqlwithsolaris-160110071313/75/Best-Practices-with-PostgreSQL-on-Solaris-23-2048.jpg)
![Basic Locks Monitoring
• Dtrace Scripts based on postgresql provider
> PostgreSQL level locking profile
#!/usr/sbin/dtrace -qs
dtrace:::BEGIN
{ lckmode[0] = "Exclusive";
lckmode[1] = "Shared"; }
postgresql*:::lwlock-startwait
{ self->ts[arg0]=timestamp;
@count[arg0, lckmode[arg1]] = count(); }
postgresql*:::lwlock-endwait
/self->ts[arg0]/
{ @time[arg0 ,lckmode[arg1]] = sum (timestamp - self->ts[arg0]);
self->ts[arg0]=0; }
dtrace:::END
{ printf("n%20s %15s %15sn", "Lock Id", "Mode", "Count");
printa("%20d %15s %@15dn",@count);
printf("n%20s %15s %20sn", "Lock Id","Mode", "Combined Time (ns)");
printa("%20d %15s %@20dn",@time); }
tick-10sec
{ exit(0);}
# ./lwlock_wait.d](https://image.slidesharecdn.com/postgresqlconferenceeast2008-bestpracticesofpostgresqlwithsolaris-160110071313/75/Best-Practices-with-PostgreSQL-on-Solaris-31-2048.jpg)
Uploaded byJignesh Shah
Best Practices with PostgreSQL on Solaris
This document provides best practices for deploying PostgreSQL on Solaris, including: - Using Solaris 10 or latest Solaris Express for support and features - Separating PostgreSQL data files onto different file systems tuned for each type of IO - Tuning Solaris parameters like maxphys, klustsize, and UFS buffer cache size - Configuring PostgreSQL parameters like fdatasync, commit_delay, wal_buffers - Monitoring key metrics like memory, CPU, and IO usage at the Solaris and PostgreSQL level
More Related Content
Similar to Best Practices with PostgreSQL on Solaris
Best Practices with PostgreSQL on Solaris
- 1. Best Practices withPostgreSQL on Solaris Jignesh Shah – Staff Engineer, ISV Engineering, Sun Microsystems Inc PostgreSQL East Conference March 2008
- 2. About Me • Workingwith Sun Microsystems for about 7 1/2 years > Primarily responsibility at Sun is to make ISV and Open Source Community Software applications work better on Solaris • Prior to Sun worked as ERP Consultant • Worked with various databases (DB2 UDB, PostgreSQL, MySQL, Progress OpenEdge, Oracle) • Worked with various ERP (QAD, Lawson) and CRM (Dispatch-1), etc • Previous responsibilities also included : Low Cost BIDW
- 3. Agenda • Deployment tips >Storage > File systems > Solaris tunables > PostreSQL tunables • Monitoring > Solaris and other tools • Summary • References
- 4. What is notcovered • Solaris Internals • PostgreSQL Internals • Replication and Clustering • High Availability
- 5. Best Practices todeploy PostgreSQL on Solaris
- 6. Solaris 10 orSolaris Express? • Start with Solaris 10 8/07 or latest Solaris Express • How to decide whether Solaris 10 8/07 or Solaris Express (or OpenSolaris binary distribution) ? > If long term support from Sun is desired use Solaris 10 8/07 > If latest version/feature of Solaris is desired without depending on Support from Sun use latest Solaris Express builds • Make sure to use at least PostgreSQL 8.2 (and not the default PostgreSQL 8.1 on Solaris 10) • For 64-bit versions and/or PostgreSQL 8.3 use latest Solaris Express builds
- 7. Understanding PostgreSQL IO •For simplified view consider three buckets of IO > $PGDATA – Includes CLOG, control file etc – All 8K, > pg_xlog, Write Ahead Log: Mostly writes: IO size 8KB-256KB (observed) (Depends on various postgresql.conf tunables) > Relation Files: Data Tables, Index, etc: IO Size 8KB Mix of reads and writes, mix of random,sequential • Similarly create at least three file systems on Solaris so each file system can be tuned according to the needs of the type of IO • Relation Files can be easily separated and/or further broken down using TABLESPACES in PostgreSQL
- 8. Setting up IOand UFS Tunable • By default, UFS aims to cache only small files. Any file bigger than 32KB (like PostgreSQL data files) is generally NOT cached for long. • By default, on X86 / X64 biggest IO is limited to 56KB by default (compared to 128KB on SPARC) • By default effective UFS cache is 12% on SPARC (segmap_percent) and only 64MB on x64 (segmapsize) • Setting Effective cache higher in PostgreSQL on Solaris without tuning UFS caching could hurt performance
- 9. Setting up IOand UFS Tunables • Increase Maximum IO Size and in effect Readahead for UFS (not in case of directio) • Set maxphys and klustsize to 1MB > set maxphys=1048576 > set klustsize=1048576 • UFS buffer map might need tuning > X86 /X64 > set ufs:freebehind=0 > set segmapsize=1073741824 > SPARC > set freebehind=0 > set segmap_percent=25
- 10. Best Practices forStorage LUNS • For LUNS exported from external storage arrays, most efficient strip size depends on postgresql.conf parameters. Start with 128K strip size. > If using commit_delay then higher stripsize is preferred (128k-256K) for log filesystem. Recommended to use RAID1 or RAID10. (Avoid RAID-5 for logs) > For other file systems , even though most common IO block size in PostgreSQL is 8K, do not use less than 32KB strip size for layouts. Recommended between 32KB-256KB depending on workload > Sequential scan from database tables and indexes is slow using lower stripsize . Bigger stripsize impacts response times specially for OLTP Workload.
- 11. Best Practices forStorage/Directory Layout (using UFS) • Start with three filesystems for PostgreSQL databases > One for $PGDATA - UFS Buffered (default) > One for $PGDATA/pg_xlog – UFS DirectIO (forcedirectio) > One for default tablespace for the database to be created - UFS Directio (forcedirectio,noatime) > (This could require noforcedirectio depending on workload)
- 12. Best Practices forStorage/Directory Layout (using ZFS) • Separate pool for log filesystem > Mirror device (no RAID-Z) with recordsize 128K > Enable commit_delay in postgresql.conf to allow logs to write multiple log records in 1 write (bigger than 8K) • Defaults good for $PGDATA • For default tablespace, defaults probably okay > (but highly workload dependent) Need to figure out the ratio of sequential scans and random Ios happening first before changing recordsize • System should not be RAM or CPU bound for ZFS to perform best
- 13. Setting up Resourcesfor User • Setup resources as follows: > projadd -U pguser user.pguser > projmod -a -K "project.max-shm-ids=(priv,32768,deny)" user.pguser > projmod -a -K "project.max-sem-ids=(priv,4096,deny)" user.pguser > projmod -a -K "project.max-shm-memory=(priv, 13589934592,deny)" user.pguser > projmod -a -K "project.max-msg-ids=(priv,4096,deny)" user.pguser • Check /etc/project > user.pguser:100::pguser::project.max-msg-ids=(priv, 4096,deny);project.max-sem-ids=(priv,4096,deny);project.max- shm-ids=(priv,32768,deny);project.max-shm-memory=(priv, 13589934592,deny) • Higher limits do not result in wasted memory but are really limited to avoid Denial of Service attacks via user logins
- 14. Best Practices forSolaris • Use libumem > LD_PRELOAD_32=/usr/lib/libumem.so; export LD_PRELOAD_32 > LD_PRELOAD_64=/usr/lib/64/libumem.so; export LD_PRELOAD_64 > $POSTGRES_HOME/bin/pg_ctl -o -i -D $PGDATA -l $PGDATA/server.log start • Use FX Scheduler > /usr/bin/priocntl -s -c FX -i projid 100
- 15. Best Practices forPostgreSQL.conf • Use fdatasync or open_datasync (default) > (Jury divided between the two. I prefer fdatasync) • Enable commit_delay for high load environment > (unlike the new async commit in 8.3, there is no loss of transactions ) • Increase checkpoint_segments • Increase wal_buffers > (when response times are critical with many users) • Default background writer parameters good in 8.2 > Background writer in 8.1 needs tuning
- 16. Best Practices forPostgreSQL.conf • Shared Bufferpool getting better in 8.2 worth to increase it to 3GB (for 32-bit PostgreSQL) but still not great to increase it more than 10GB (for 64-bit PostgreSQL) • Temp buffers and work mem are workload dependent > (For high number of connections they have x max connections impact – sometimes more than connections) • Maintenance work mem is good between 256MB to 512MB • (Meant for bigger than 5GB database - Ofcourse)
- 17. Best Practices forGlassfish • Use Extra JDBC Wrapper driver to cache statements in Glassfish • Number of steady connections should be increased with caution beyond 100
- 18. Other Tips forDeployment • If you are using multiple applications or instances use separate userids or projectids to make monitoring easy (Zones/Containers are also another easy options) • If you plan to use CPU usage “limits” by application (by using Resource Constraints feature of Solaris Containers), allow some time to gather statistical data first on its CPU usage
- 19. Monitoring PostgreSQLon Solaris SunFire X4150 (2 Socket, 8 Cores) Project user.pguser: PostgreSQL User Project user.app Glassfish App Server Project default: Everything else Note:This is just an example and not an actual recommendation for Sun Fire X4150. Actual distribution should consider all applications running on the system.
- 20. Monitoring PostgreSQLon Solaris SunFire X4150 (2 Socket, 8 Cores) Project user.pguser: PostgreSQL User Project user.appuer Glassfish App Server Project default: Everything else MemoryMonitoring BasicLockMonitoring IO Monitoring by Filesystems CPU Utilization monitoring
- 21. Memory Monitoring • vmstat3 > Keep an eye on swap/free memory # vmstat 3 kthr memory page disk faults cpu r b w swap free re mf pi po fr de sr s0 s1 s2 s3 in sy cs us sy id 0 0 0 1600992 2622832 0 6 0 0 0 0 0 0 0 0 0 1018 287 475 1 1 98 0 0 0 1347744 2400480 31 37 0 0 0 0 0 0 0 0 0 1061 2772 900 23 2 75 0 0 0 1282420 2335524 0 0 0 0 0 0 0 0 0 0 0 1053 2728 899 24 2 74 0 0 0 1217088 2270192 0 0 0 0 0 0 0 0 0 0 0 1057 2653 889 23 2 75
- 22. Memory Monitoring • prstat-a > Memory usage by process (rough aggregation by user) Total: 55 processes, 188 lwps, load averages: 1.02, 0.82, 0.44 PID USERNAME SIZE RSS STATE PRI NICE TIME CPU PROCESS/NLWP 20787 pguser 3173M 3166M cpu0 0 0 0:08:29 25% postgres/1 20789 root 3332K 2804K cpu3 59 0 0:00:01 0.1% prstat/1 133 root 4296K 3284K sleep 59 0 0:00:00 0.0% picld/4 142 root 3536K 2344K sleep 59 0 0:00:00 0.0% devfsadm/6 290 daemon 2036K 1288K sleep 60 -20 0:00:00 0.0% lockd/2 20772 root 2648K 1716K sleep 59 0 0:00:00 0.0% bash/1 291 root 2268K 1180K sleep 59 0 0:00:00 0.0% keyserv/3 138 daemon 3956K 2012K sleep 59 0 0:00:00 0.0% kcfd/3 1982 root 6888K 3504K sleep 59 0 0:01:53 0.0% nscd/28 299 root 2132K 1324K sleep 59 0 0:00:00 0.0% ttymon/1 292 root 1752K 944K sleep 59 0 0:00:01 0.0% sac/1 348 root 2456K 996K sleep 59 0 0:00:00 0.0% cron/1 272 daemon 2536K 1348K sleep 59 0 0:01:20 0.0% rpcbind/1 9 root 10M 9440K sleep 59 0 0:01:22 0.0% svc.configd/17 7 root 12M 11M sleep 59 0 0:00:41 0.0% svc.startd/13 NPROC USERNAME SWAP RSS MEMORY TIME CPU 8 pguser 3175M 3178M 20% 0:28:15 25% 40 root 68M 76M 0.5% 0:41:52 0.1% 1 smmsp 1260K 4132K 0.0% 0:00:01 0.0% 6 daemon 27M 28M 0.2% 0:01:26 0.0% Total: 55 processes, 188 lwps, load averages: 1.02, 0.83, 0.44
- 23. Memory Monitoring • pmap-sax $pid > To understand the details of memory consumption of a process # pmap -sax 20787 20787: /export/home/postgres/pgsql/bin/postgres Address Kbytes RSS Anon Locked Pgsz Mode Mapped File 0000000000400000 4 4 - - 4K r-x-- postgres 0000000000401000 340 - - - - r-x-- postgres .. 0000000000C80000 12 12 12 - 4K rw--- [ heap ] 0000000000C83000 4 - - - - rw--- [ heap ] 0000000000C84000 4 4 4 - 4K rw--- [ heap ] FFFFFD7F00000000 120832 120832 120832 120832 2M rwxsR [ ism shmid=0x36 ] FFFFFD7F07600000 3115440 3115440 3115440 3115440 4K rwxsR [ ism shmid=0x36 ] FFFFFD7FFF010000 64 8 - - - rwx-- [ anon ] FFFFFD7FFF040000 4 4 - - - rwx-- [ anon ] FFFFFD7FFF050000 16 16 - - 4K r-x-- en_US.ISO8859-1.so.3 ... FFFFFD7FFFDF7000 20 20 20 - 4K rw--- [ stack ] FFFFFD7FFFDFC000 12 12 - - - rw--- [ stack ] FFFFFD7FFFDFF000 4 4 4 - 4K rw--- [ stack ] ---------------- ---------- ---------- ---------- ---------- total Kb 3247600 3245420 3239316 3236272
- 24. IO Monitoring • iostat-xcznpm 3 > Figure out if IO is distributed well enough on various devices. Keep an eye on %b (busy) and asvc_t # iostat -xcznmp 3 .... cpu us sy wt id 25 1 0 74 extended device statistics r/s w/s kr/s kw/s wait actv wsvc_t asvc_t %w %b device 29.3 0.0 3754.6 0.0 0.7 0.1 23.3 2.2 6 6 c5t5d0 29.3 0.0 3754.6 0.0 0.7 0.1 23.3 2.2 6 6 c5t5d0s0 29.0 0.0 3712.0 0.0 0.7 0.1 23.4 2.2 6 6 c6t5d0s0 28.0 0.0 3584.0 0.0 0.6 0.1 22.4 2.1 6 6 c7t5d0s0 29.0 0.0 3712.0 0.0 0.7 0.1 23.4 2.2 6 6 c4t5d0s0 27.7 0.0 3541.3 0.0 0.6 0.1 22.1 2.1 6 6 c1t5d0s0 27.7 0.0 3541.3 0.0 0.8 0.1 30.5 2.7 7 8 c0t5d0s0 29.0 0.0 3712.0 0.0 0.7 0.1 23.4 2.2 6 6 c6t5d0 28.0 0.0 3584.0 0.0 0.6 0.1 22.4 2.1 6 6 c7t5d0 29.0 0.0 3712.0 0.0 0.7 0.1 23.4 2.2 6 6 c4t5d0 27.7 0.0 3541.3 0.0 0.6 0.1 22.1 2.1 6 6 c1t5d0 27.7 0.0 3541.3 0.0 0.8 0.1 30.5 2.7 7 8 c0t5d0
- 25. IO Monitoring • fsstat/mountpoints 3 > IO by filesystems # fsstat /pgtbs2 3 new name name attr attr lookup rddir read read write write file remov chng get set ops ops ops bytes ops bytes 68.9K 235 0 28.1M 17 259K 162 362M 2.83T 86.5M 692G /pgtbs2 0 0 0 0 0 0 0 7.72K 61.7M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.65K 61.2M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.55K 60.4M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.72K 61.7M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.64K 61.1M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.38K 59.1M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.58K 60.6M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.59K 60.7M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.61K 60.9M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.65K 61.2M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.68K 61.4M 0 0 /pgtbs2 0 0 0 0 0 0 0 7.59K 60.7M 0 0 /pgtbs2
- 26. IO Monitoring • zpooliostat 3 > If ZFS pools are used, then a simplified iostat by pool # zpool iostat 5 capacity operations bandwidth pool used avail read write read write ---------- ----- ----- ----- ----- ----- ----- pgdata 108G 2.16T 1 4 87.1K 141K pglog 43.7G 2.22T 0 0 25.4K 52.4K pgtbs1 24.4G 3.15T 3 0 310K 37.7K pgtbs2 90.5G 2.63T 9 1 1.13M 95.8K pgtbs3 93.0G 2.63T 1 0 97.8K 47.2K pgtbs4 20.5G 2.70T 5 0 620K 45.8K pgtbs5 13.6G 3.16T 0 0 91.4K 18.6K pgtbs6 6.12G 1.81T 0 0 66.2K 22.8K ---------- ----- ----- ----- ----- ----- ----- pgdata 108G 2.16T 0 0 0 0 pglog 43.7G 2.22T 0 0 0 0 pgtbs1 24.4G 3.15T 0 0 0 0 pgtbs2 90.5G 2.63T 153 0 19.1M 0 pgtbs3 93.0G 2.63T 0 0 0 0 pgtbs4 20.5G 2.70T 0 0 0 0 pgtbs5 13.6G 3.16T 0 0 0 0 pgtbs6 6.12G 1.81T 0 0 0 0 ---------- ----- ----- ----- ----- ----- -----
- 27. CPU Monitoring • prstat-am / prstat -Jm > CPU utilization by process and aggregation by user/Project id PID USERNAME USR SYS TRP TFL DFL LCK SLP LAT VCX ICX SCL SIG PROCESS/NLWP 20787 pguser 96 2.5 0.0 0.0 0.0 0.0 1.1 0.0 2 62 13K 0 postgres/1 20814 root 0.0 0.7 0.0 0.0 0.0 0.0 99 0.0 21 0 198 0 prstat/1 268 root 0.0 0.1 0.0 0.0 0.0 0.0 100 0.0 3 0 37 0 in.routed/1 16643 pguser 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 68 3 69 0 postgres/1 16644 pguser 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 78 1 94 0 postgres/1 20615 root 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 15 0 30 0 iosum_amd/1 272 daemon 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 1 0 8 0 rpcbind/1 20758 root 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 2 0 16 0 sshd/1 570 root 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 5 0 7 0 snmpd/1 16645 pguser 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 8 0 6 0 postgres/1 9122 root 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 3 0 10 0 sendmail/1 133 root 0.0 0.0 0.0 0.0 0.0 25 75 0.0 0 0 0 0 picld/4 142 root 0.0 0.0 0.0 0.0 0.0 50 50 0.0 0 0 0 0 devfsadm/6 290 daemon 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 0 0 0 0 lockd/2 20772 root 0.0 0.0 0.0 0.0 0.0 0.0 100 0.0 0 0 0 0 bash/1 NPROC USERNAME SWAP RSS MEMORY TIME CPU 8 pguser 3175M 3178M 20% 0:44:40 25% 40 root 68M 76M 0.5% 0:41:51 0.1% 6 daemon 27M 28M 0.2% 0:01:26 0.0% 1 smmsp 1260K 4132K 0.0% 0:00:01 0.0% Total: 55 processes, 188 lwps, load averages: 1.01, 1.00, 0.82
- 28. CPU Monitoring • mpstat5 > Utilization by CPU useful to see if one of them is more stressed while there are idle CPUs available # mpstat 5 CPU minf mjf xcal intr ithr csw icsw migr smtx srw syscl usr sys wt idl 0 2 0 148 482 263 179 3 20 11 0 94 2 0 0 98 1 1 0 168 167 3 175 3 19 10 0 77 1 0 0 99 2 2 0 47 215 62 65 2 13 8 0 63 1 1 0 98 3 1 0 41 155 6 56 2 7 8 0 54 1 1 0 98 CPU minf mjf xcal intr ithr csw icsw migr smtx srw syscl usr sys wt idl 0 0 0 0 384 248 2 11 1 1 0 2519 94 4 0 2 1 0 0 13 196 2 331 0 25 9 0 26 0 1 0 99 2 2 0 93 391 305 266 1 24 8 0 35 0 2 0 98 3 0 0 0 158 4 235 0 11 5 0 72 2 0 0 98 CPU minf mjf xcal intr ithr csw icsw migr smtx srw syscl usr sys wt idl 0 0 0 0 414 247 184 5 19 6 0 1256 47 2 0 51 1 0 0 13 93 2 169 6 16 4 0 1148 42 2 0 56 2 0 0 0 298 230 198 2 23 8 0 113 3 2 0 95 3 0 0 1 73 4 130 0 11 5 0 129 4 0 0 96 CPU minf mjf xcal intr ithr csw icsw migr smtx srw syscl usr sys wt idl 0 0 0 0 14546 250 82 13 8 5 0 2428 92 6 0 2 1 0 0 42457 185 2 359 1 32 13 0 14 0 5 0 94 2 0 0 1 14635 382 326 0 35 16 0 36 0 4 0 96 3 0 0 17 14332 4 302 1 20 10 0 22 0 2 0 98
- 29. Basic Locks Monitoring •lockstat sleep 5 > Kernel level locking profile # lockstat sleep 5 Adaptive mutex spin: 156 events in 5.022 seconds (31 events/sec) Count indv cuml rcnt spin Lock Caller ------------------------------------------------------------------------------- 67 43% 43% 0.00 4 0xffffffffa4af99a8 taskq_thread+0xe3 22 14% 57% 0.00 4 0xffffffffa4af99a8 cv_wait+0x70 ... ------------------------------------------------------------------------------- Adaptive mutex block: 2 events in 5.022 seconds (0 events/sec) Count indv cuml rcnt nsec Lock Caller ------------------------------------------------------------------------------- 1 50% 50% 0.00 8587 0xffffffffa4af99a8 taskq_dispatch+0x1b8 1 50% 100% 0.00 6383 0xffffffffa4af99a8 cv_wait+0x70 ------------------------------------------------------------------------------- Spin lock spin: 21 events in 5.022 seconds (4 events/sec) Count indv cuml rcnt spin Lock Caller ------------------------------------------------------------------------------- 7 33% 33% 0.00 6 cpu0_disp disp_lock_enter+0x1e 5 24% 57% 0.00 6 cpu0_disp disp_lock_enter_high+0x9 ------------------------------------------------------------------------------- Thread lock spin: 1 events in 5.022 seconds (0 events/sec) Count indv cuml rcnt spin Lock Caller ------------------------------------------------------------------------------- 1 100% 100% 0.00 7123 transition_lock ts_update_list+0x52 -------------------------------------------------------------------------------
- 30. Basic Locks Monitoring •plockstat -p $pid > User Process level locking profile. Useful when prstat -am option shows value under LCK #
- 31. Basic Locks Monitoring •Dtrace Scripts based on postgresql provider > PostgreSQL level locking profile #!/usr/sbin/dtrace -qs dtrace:::BEGIN { lckmode[0] = "Exclusive"; lckmode[1] = "Shared"; } postgresql*:::lwlock-startwait { self->ts[arg0]=timestamp; @count[arg0, lckmode[arg1]] = count(); } postgresql*:::lwlock-endwait /self->ts[arg0]/ { @time[arg0 ,lckmode[arg1]] = sum (timestamp - self->ts[arg0]); self->ts[arg0]=0; } dtrace:::END { printf("n%20s %15s %15sn", "Lock Id", "Mode", "Count"); printa("%20d %15s %@15dn",@count); printf("n%20s %15s %20sn", "Lock Id","Mode", "Combined Time (ns)"); printa("%20d %15s %@20dn",@time); } tick-10sec { exit(0);} # ./lwlock_wait.d
- 32. DTrace Monitoring • Todebug specific issues based on outputs of previous tools • Recommended to use Dtrace Toolkit for easy scripts for most common scripts
- 33. DTrace Monitoring • Examples:Scripts from DTrace Toolkit • http://www.opensolaris.org/os/community/dtrace/dtracetoolkit/ # ./hotuser -p 20787 Sampling... Hit Ctrl-C to end. ^C FUNCTION COUNT PCNT postgres`mdread 1 0.0% postgres`smgrread 1 0.0% .... libc.so.1`memcpy 1789 5.2% postgres`AllocSetFree 1949 5.7% postgres`numeric_add 2087 6.1% postgres`add_abs 2979 8.7% postgres`AllocSetAlloc 4092 12.0% # ./prustat -p 20787 5 PID %CPU %Mem %Disk %Net COMM 20787 24.52 19.87 0.00 0.00 postgres PID %CPU %Mem %Disk %Net COMM 20787 24.47 19.87 0.37 0.00 postgres PID %CPU %Mem %Disk %Net COMM 20787 24.47 19.87 0.34 0.00 postgres PID %CPU %Mem %Disk %Net COMM 20787 24.50 19.87 0.32 0.00 postgres
- 34. Performance Of PostgreSQL onSolaris
- 35. PostgreSQL on Solaris:Performance • Published 2 SpecJAppServer2004 result using PostgreSQL 8.2 on Solaris > 778.14 JOPS with Glassfish v1 > 813.73 JOPS with Glassfish v2 Mandatory Disclosure: SPECjAppServer2004 JOPS@standard Sun Fire X4200 M2 (4 chips, 8 cores) - 813.73 SPECjAppServer2004 JOPS@Standard Sun Fire X4200 M2 (6 chips, 12cores) - 778.14 SPECjAppServer2004 JOPS@Standard SPEC, SPECjAppServer reg tm of Standard Performance Evaluation Corporation. All results from www.spec.org as of Jan 8,2008
- 36. PostgreSQL on Solaris: Scalability
- 37. Summary • File systemlayout and tuning key to Performance with PostgreSQL on Solaris • Make use of default tablespace for database – Easier to Monitor and Tune • Solaris tools including DTrace are your friends in understanding bottlenecks with PostgreSQL on Solaris
- 38. More Information • PostgreSQLQuestion: <postgresql-question@sun.com> • Blogs on PostgreSQL > Josh Berkus: http://blogs.ittoolbox.com/database/soup > Jignesh Shah: http://blogs.sun.com/jkshah/ > Tom Daly: http://blogs.sun.com/tomdaly/ > Robert Lor: http://blogs.sun.com/robertlor/ • PostgreSQL on Solaris Wiki: http://wikis.sun.com/display/DBonSolaris/PostgreSQL • OpenSolaris databases community: databases-discuss@opensolaris.org
- 39.
- 40.
- 41. PostgreSQL for Solaris •Integrated into Solaris package > Optimized to perform on Solaris > Incorporated Solaris performance and security features > ZFS > DTrace > Zones > Most reliable and secure DB/OS product > No licensing fees • Global, 24x7, enterprise-level support from Sun > Service contract available for “PostgreSQL for Solaris” > Community support is also available from PostgreSQL.org
- 42. What's included andwhat's coming? • Included > PostgreSQL Core distribution (32-bit) > PostgreSQL JDBC Driver > Most of PostgreSQL Contrib modules > Optional procedural languages PL/pgSQL, PL/perl, PL/Python and PL/Tcl > Supports OpenSSL and Kerberos • Coming soon: > PgAdmin III GUI for PostgreSQL > PostgreSQL Distribution (64-bit)
- 43. What is inSolaris 10? • Solaris 10 6/06 (U2) > PostgreSQL 8.1.2 (32-bit) • Solaris 10 11/06 (U3) > PostgreSQL 8.1.4 (32-bit) • Solaris 10 8/07 (U4) > PostgreSQL 8.1.9 (32-bit) and PostgreSQL 8.2.4 (32-bit) > Latest Patch upgrade available to 8.2.6 and 8.1.11 for Solaris 10 • Solaris 10 (U5) (Coming Soon) > PgAdminIII
- 44. What is inSolaris Express and OpenSolaris? • Solaris Express build 79a (Developer Release) > PostgreSQL 8.2.5 and 8.1.10 > PgAdminIII • Solaris Express build 87+ > PostgreSQL 8.3 (32-bit) as well as 8.3 (64-bit) • OpenSolaris Developer Preview (Project Indiana ) > Use pkg(5) to get PostgreSQL 8.2, 8.1 releases
