Decision tree Using c4.5 Algorithm
The document describes the C4.5 algorithm for building decision trees. It begins with an overview of decision trees and the goals of minimizing tree levels and nodes. It then outlines the steps of the C4.5 algorithm: 1) Choose the attribute that best differentiates training instances, 2) Create a tree node for that attribute and child nodes for each value, 3) Recursively create subordinate nodes until reaching criteria or no remaining attributes. An example applies these steps to build a decision tree to predict customers' responses to a life insurance promotion using attributes like age, income and insurance status.
In this document
Powered by AI
Introduction by Mohd Noor Abdul Hamid; overview of learning objectives.
Explains decision tree construction, minimizing tree levels and nodes using the C4.5 algorithm.
Exercise scenario involving the BIGG Credit Card company utilizing customer data to develop a predictive model.
Details on dataset (15 instances, 10 attributes), relevant input/output variables.
C4.5 attribute selection using goodness score to determine the best attribute for decision making.
Calculations of Goodness Scores for attributes: Income Range, Credit Card Insurance, Sex.
Analysis of Age attribute, introducing methods for numerical splits, aimed at improving data generalization.
Detailed steps for determining split points and their goodness scores; focuses on the best split for Age.
Determination of Age as the chosen attribute for the decision tree's top node. Steps to create a decision tree with Age as root; classification outcomes based on further subdivisions.
Model classification performance (93% accuracy); assignment to develop an application based on tree model.
More Related Content
Similar to Decision tree Using c4.5 Algorithm
Decision tree Using c4.5 Algorithm
- 1. Mohd Noor AbdulHamid, Ph.D Universiti Utara Malaysia mohdnoor@uum.edu.my
- 2. After this class,you should be able to : Explain the C4.5 Algorithm Use the algorithm to develop a Decision Tree mohdnoor@uum.edu.my
- 3. Decision tree areconstructed using only those attributes best able to differentiate the concepts to be learned. Main goal is to minimize the number of tree levels and tree nodes maximizing data generalization mohdnoor@uum.edu.my
- 4. The C4.5 Algorithm LetT be the set of training instances Choose an attribute that best differentiates the instances contained in T. mohdnoor@uum.edu.my
- 5. Let T bethe set of training instances Choose an attribute that best differentiates the instances contained in T. The C4.5 Algorithm Create a tree node whose value is the chosen attribute. Create child links from this node where each link represents a unique value for the chosen attribute. Use the child link values to further subdivide the instances into subclasses.
- 6. Let T bethe set of training instances Choose an attribute that best differentiates the instances contained in T. Create a tree node whose value is the chosen attribute. Create child links from this node where each link represents a unique value for the chosen attribute. Use the child link values to further subdivide the instances into subclasses. The C4.5 Algorithm Instances in the subclass satisfy predefine criteria OR Remaining attributes choice for the path is null
- 7. Create a treenode whose value is the chosen attribute. Create child links from this node where each link represents a unique value for the chosen attribute. Use the child link values to further subdivide the instances into subclasses. Instances in the subclass satisfy predefine criteria OR Remaining attributes choice for the path is null Specify the classification for new instances following this decision path Y The C4.5 Algorithm
- 8. Use the childlink values to further subdivide the instances into subclasses. Instances in the subclass satisfy predefine criteria OR Remaining attributes choice for the path is null Specify the classification for new instances following this decision path Y The C4.5 Algorithm N
- 9. Let T bethe set of training instances Choose an attribute that best differentiates the instances contained in T. Create a tree node whose value is the chosen attribute. Create child links from this node where each link represents a unique value for the chosen attribute. Use the child link values to further The C4.5 Algorithm END
- 10.
- 11. Exercise : TheScenario • BIGG Credit Card company wish to develop a predictive model in order to identify customers who are likely to take advantage of the life insurance promotion – so that they can mail the promotional item to the potential customer.
- 12. Exercise : TheScenario The model will be develop using the data stored in the credit card promotion database. The data contains information obtained about customers through their initial credit card application as well as data about whether these individual have accepted various promotional offerings sponsored by the company Dataset
- 13. Let T beset of training instances Exercise We follow our previous work with creditcardpromotion.xls The dataset consist of 15 instances (observations)- T, each having 10 attributes (variables) for our example, the input attributes are limited to 5. Why?? Step 1 Decision tree are constructed using only those attributes best able to differentiate the concepts to be learned.
- 14. Let T beset of training instances Exercise Step 1 Age Interval 19 – 55 years Independent Variables (Inputs) Sex Nominal Male Female Income Range Ordinal 20 – 30K 30 – 40K 40 – 50K 50 – 60K Credit Card Insurance Binary Yes No Life Insurance Promotion Binary Yes No Dependent Variables (Target / Output)
- 15. Choose an attributethat best differentiates the instances contained in T Exercise C4.5 uses measure taken from information theory to help with the attribute selection process. The idea is; for any choice point in the tree, C4.5 selects the attributes that splits the data so as to show the largest amount of gain in information. We need to choose an input attribute to best differentiate the instances in T our choices are among : - Income Range - Credit Card Insurance - Sex - Age Step 2 INSURED
- 16. Choose an attributethat best differentiates the instances contained in T Exercise Goodness Score for each attribute is calculated to determined which attribute best differentiate the training instances (T). Step 2 Sum of the most frequently encountered class in each branch (level) ÷ T Number of branches (levels) Goodness Score We can develop a partial tree for each attribute in order to calculate the Goodness Score. Sum of the most frequently encountered class in each branch (level) ÷ T Number of branches (levels) Goodness Score Accuracy
- 17. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2a. Income Range
- 18. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2a. Income Range Income Range 2 Yes 2 No 20 – 30K 4 Yes 1 No 30-40K 1 Yes 3 No 40-50K 2 Yes 50-60K
- 19. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2a. Income Range Sum of the most frequently encountered class in each branch (level) ÷ T Number of branches (levels) Goodness Score = (2 + 4 + 3 + 2) ÷ 15 4 = 0.183
- 20. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2b. Credit Card Insurance
- 21. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2b. Credit Card Insurance CC Insurance 6 Yes 6 No No 3 Yes 0 No Yes
- 22. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2b. Credit Card Insurance Sum of the most frequently encountered class in each branch (level) ÷ T Number of branches (levels) Goodness Score = (6 + 3) ÷ 15 2 = 0.30
- 23. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2c. Sex
- 24. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2c. Sex Sex 3 Yes 5 No Male 6 Yes 1 No Female
- 25. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2c. Sex Sum of the most frequently encountered class in each branch (level) ÷ T Number of branches (levels) Goodness Score = (6 + 5) ÷ 15 2 = 0.367
- 26. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Age is an interval variable (numeric), therefore we need to determine where is the best split point for all the values. For this example, we are opt for binary split. Why?? Main goal is to minimize the number of tree levels and tree nodes maximizing data generalization
- 27. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Steps to determine the best splitting point for interval (numerical) attribute: 1. Sort the Age values (pair with the target – Life Ins Promo) Age 19 27 29 35 38 39 40 41 42 43 43 43 45 55 55 LIP Y N Y Y Y Y Y Y N Y Y N N N N
- 28. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Steps to determine the best splitting point for interval (numerical) attribute (Age): 2. A Goodness Score is computed for each possible split point Age 19 27 29 35 38 39 40 41 42 43 43 43 45 55 55 LIP Y N Y Y Y Y Y Y N Y Y N N N N 1 Yes 0 No 8 Yes 6 No Goodness Score = (1 + 8) ÷ 15 = 0.30 2
- 29. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Steps to determine the best splitting point for interval (numerical) attribute (Age): 2. A Goodness Score is computed for each possible split point Age 19 27 29 35 38 39 40 41 42 43 43 43 45 55 55 LIP Y N Y Y Y Y Y Y N Y Y N N N N 1 Yes 1 No 8 Yes 5 No Goodness Score = (1 + 8) ÷ 15 = 0.30 2
- 30. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Steps to determine the best splitting point for interval (numerical) attribute (Age): 2. A Goodness Score is computed for each possible split point This process continues until a score for the split between 45 and 55 is obtained. Split point with the highest Goodness Score is chosen 43.
- 31. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Steps to determine the best splitting point for interval (numerical) attribute (Age): 2. A Goodness Score is computed for each possible split point Age 19 27 29 35 38 39 40 41 42 43 43 43 45 55 55 LIP Y N Y Y Y Y Y Y N Y Y N N N N 9 Yes 3 No 0 Yes 3 No Goodness Score = (9 + 3) ÷ 15 = 0.40 2
- 32. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 2d. Age Age 9 Yes 3 No ≤ 43 0 Yes 3 No > 43
- 33. Choose an attributethat best differentiates the instances contained in T Exercise Step 2 Overall Goodness Score for each input attribute: Attribute Goodness Score Age 0.4 Sex 0.367 Credit Card Insurance 0.3 Income Range 0.183 Therefore the attribute Age is chosen as the top level node
- 34. • Create atree node whose value is the chosen attribute. • Create child links from this node where each link represents a unique value for the chosen attribute. Exercise Step 3
- 35. Exercise Step 3 Age 9 Yes 3No ≤ 43 0 Yes 3 No > 43
- 36. For each subclass: a. If the instances in the subclass satisfy the predefined criteria or if the set of remaining attribute choices for this path is null, specify the classification for new instances following this decision. b. If the subclass does not satisfy the predefined criteria and there is at least one attribute to further subdivide the path of the three, let T be the current set of subclass instances and return to step 2. Exercise Step 3 mohdnoor@uum.edu.my
- 37. Exercise Step 3 Age 9 Yes 3No ≤ 43 0 Yes 3 No > 43 Does not satisfy the predefine criteria. Subdivide! Satisfy the predefine criteria. Classification : Life Insurance = No mohdnoor@uum.edu.my
- 38. Step 3 Age ≤ 43 0Yes 3 No > 43 Life Insurance = Yes Sex Exercise Female 6 Yes 0 No Male 3 Yes 3 No Life Insurance = Yes Subdivide mohdnoor@uum.edu.my
- 39. Age ≤ 43 0 Yes 3No > 43 Life Insurance = Yes Sex Female 6 Yes 0 No Male Life Insurance = Yes Exercise Step 3 CC Insurance 1 Yes 3 No No 2 Yes 0 No Yes Life Insurance = No Life Insurance = Yes mohdnoor@uum.edu.my
- 40. Age ≤ 43 0 Yes 3No > 43 Life Insurance = No Sex Female 6 Yes 0 No Male Life Insurance = Yes Exercise CC Insurance 1 Yes 3 No No 2 Yes 0 No Yes Life Insurance = No Life Insurance = Yes The Decision Tree: Life Insurance Promo
- 41. Exercise The Decision Tree: 1.Our Decision Tree is able to accurately classify 14 out of 15 training instances. 2. Therefore, the accuracy of our model is 93%
- 42. Assignment • Based onthe Decision Tree model for the Life Insurance Promotion, develop application (program) using any tools you are familiar with. • Submit your code and report next week! mohdnoor@uum.edu.my
