  ARDUINO –BLUETOOTH BASED HOMEAUTOMATION PRESENTATION BY Sourav Roy (59) Saswata Baral (07) Aqsa Nasim Khan (41) Shoumosree Mondal (46)
• 2.
  INDEX • INTRODUCTION TOTHE PROJECT • HARDWARE REQUIRED • BLOCK DIAGRAM • PROCESS OF MAKING RELAY CIRCUIT • SOFTWARE USED • ADVANTAGES • DISADVANTAGES • REFERENCES
• 3.
  INTRODUCTION 1. To developa Bluetooth based home automation system with Arduino-UNO Board and an Android application. 2. Remote controlled home automation system provides a simpler solution with Android application technology. 3. Remote operation is achieved by any smart phone/Tablet etc.
• 4.
  HARDWARE REQUIREMENTS • ArduinoUNO • Bluetooth Module -HC-05 • 12V Relay • Smart Phone • LED Lights • Power Supply 230v,50Hz. • Switch board
• 5.
  BLOCK DIAGRAM
• 6.
  CIRCUIT DIAGRAM
• 7.
   The ArduinoUno is a microcontroller board based on the ATmega328P.  It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16 MHz quartz crystal, a USB connection, a power jack, an ICSP header and a reset button.  Simply connect it to a Computer with a USB cable or power it with a AC-to-DC adapter or battery to get started ARDUINO UNO
• 9.
   MICROCONTROLLER ATMEGA328P  OPERATING VOLTAGE 5V  DIGITAL I/O PINS 14  PWM DIGITAL I/O PINS 6  ANALOG INPUT PINS 6  FLASH MEMORY 32KB  CLOCK SPEED 16MHZ ARDUINO UNO SPECIFICATIONS
• 10.
  BLUETOOTH MODULE  Forthe communication between mobile phone andmicrocontroller Bluetooth module (HC-05) is used.  HC-05 is low power 1.8V operation and is easy to use with Bluetooth SPP (serial port protocol).
• 12.
  RELAY  Relay isbasically an electromagnetic switch which can be turn ON and OFF by applying the voltage across its contacts.  In this project we used a 12V 5 pin relay
• 14.
  SOFTWARE USED PROGRAMMING LANGUAGE ARDUINOIDE EMBEDDED C/C++
• 15.
  ADVANTAGES  It isa robust and easy to use system.  It will save your energy and money.  Provides Security.  Convenience and comfort.  Can be used by physically challenged and disabled people.  Complexity is less as only a single mobile is used multiple devices.  Smart home technology.
• 16.
  DISADVANTAGES Only works forlimited range or short distance with in 5-10m surroundings. No feedback path. Number of appliances which can be controlled through this circuit are limited. Circuit complexity increases as number of devices increase.
• 17.
  FUTURE WORK  Thissetup can further be developed into IOT project by using Ethernet arduino and a wifi module.  So , it can be controlled from anywhere around the globe having feedback from the devices to further improve the energy savings.
• 18.
  REFERENCES •www.atmel.com •www.arduino.org •www.beyondlogic.org •www.wikipedia.org
• 19.
  THANK YOU FOR YOUR ATTENTION
