The Function Pointer Tutorials

The Function Pointer Tutorials
Introduction to C and C++ Function Pointers, Callbacks and Functors

written by Lars Haendel
January 2002, Dortmund, Germany
http://www.newty.de
email: lore@newty.de
version 2.041b

Copyright (c) 2000-2002 by Lars Haendel. Permission is granted to copy,
distribute and/or modify this document under the terms of the GNU Free
Documentation License, Version 1.1 or any later version published by the
Free Software Foundation; with no Invariant Sections, with the Front-
Cover Text being the text from the title up to the table of contents, and
with no Back-Cover Texts. A copy of the license can be obtained from
http://www.gnu.org .
Be aware that there may be a newer version of this document! Check
http://www.newty.de/zip/e fpt.pdf for the latest release. If you want to
distribute this document, I suggest you to link to the URL above to prevent
spreading of outdated versions.
You may also download the source code of the examples at
http://www.newty.de/zip/source.zip . The example code is free software
under the terms of the GNU General Public License.

Contents
1 Introduction to Function Pointers 2
1.1 What is a Function Pointer ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Introductory Example or How to Replace a Switch-Statement . . . . . . . . . . . . . . . . . . . . 2

2 The Syntax of C and C++ Function Pointers 3
2.1 Deﬁne a Function Pointer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Calling Convention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.3 Assign an Address to a Function Pointer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4 Comparing Function Pointers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.5 Calling a Function using a Function Pointer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.6 How to Pass a Function Pointer as an Argument ? . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.7 How to Return a Function Pointer ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.8 How to Use Arrays of Function Pointers ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 How to Implement Callback Functions in C and C++ 7
3.1 Introduction to the Concept of Callback Functions . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 How to Implement a Callback in C ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Example Code of the Usage of qsort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 How to Implement a Callback to a static C++ Member Function ? . . . . . . . . . . . . . . . . . 8
3.5 How to Implement a Callback to a non-static C++ Member Function ? . . . . . . . . . . . . . . 9

4 Functors to encapsulate C and C++ Function Pointers 11
4.1 What are Functors ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 How to Implement Functors ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Example of How to Use Functors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1

1 Introduction to Function Pointers
Function Pointers provide some extremely interesting, efficient and elegant programming techniques. You can
use them to replace switch/if-statements, to realize your own late-binding or to implement callbacks. Unfor-
tunately – probably due to their complicated syntax – they are treated quite stepmotherly in most computer
books and documentations. If at all, they are addressed quite briefly and superficially. They are less error prone
than normal pointers cause you will never allocate or de-allocate memory with them. All you’ve got to do is
to understand what they are and to learn their syntax. But keep in mind: Always ask yourself if you really
need a function pointer. It’s nice to realize one’s own late-binding but to use the existing structures of C++
may make your code more readable and clear. One aspect in the case of late-binding is runtime: If you call a
virtual function, your program has got to determine which one has got to be called. It does this using a V-Table
containing all the possible functions. This costs some time each call and maybe you can save some time using
function pointers instead of virtual functions. Maybe not ... 1

1.1 What is a Function Pointer ?
Function Pointers are pointers, i.e. variables, which point to the address of a function. You must keep in mind,
that a running program gets a certain space in the main-memory. Both, the executable compiled program code
and the used variables, are put inside this memory. Thus a function in the program code is, like e.g. a character
field, nothing else than an address. It is only important how you, or better your compiler/processor, interpret
the memory a pointer points to.

1.2 Introductory Example or How to Replace a Switch-Statement
When you want to call a function DoIt() at a certain point called label in your program, you just put the call
of the function DoIt() at the point label in your source code. Then you compile your code and every time your
program comes up to the point label, your function is called. Everything is ok. But what can you do, if you
don’t know at build-time which function has got to be called? What do you do, when you want to decide it
at runtime? Maybe you want to use a so called Callback-Function or you want to select one function out of a
pool of possible functions. However you can also solve the latter problem using a switch-statement, where you
call the functions just like you want it, in the different branches. But there’s still another way: Use a function
pointer! In the following example we regard the task to perform one of the four basic arithmetic operations.
The task is first solved using a switch-statement. Then it is shown, how the same can be done using a function
pointer.2

//-----------------------------------------------------------------------------------------
// 1.2 Introductory Example or How to Replace a Switch-Statement
// Task: Perform one of the four basic arithmetic operations specified by the
// characters ’+’, ’-’, ’*’ or ’/’.

#include <iostream.h> // due to: cout

// the four arithmetic operations
// one of these functions is selected at runtime with a switch or a function pointer
float Plus (float a, float b) { return a+b; }
float Minus (float a, float b) { return a-b; }
float Multiply (float a, float b) { return a*b; }
float Divide (float a, float b) { return a/b; }

// solution with a switch-statement - <opCode> specifies which operation to execute
void Switch(float a, float b, char opCode)
{
float result;
switch(opCode) // execute operation
{
case ’+’ : result = Plus (a, b); break;
case ’-’ : result = Minus (a, b); break;
1 Modern compilers are very good! With my Borland Compiler the time I was able to save calling a virtual function which

multiplies two floats was about 2 percent.
2 It’s only an example and the task is so easy that I suppose nobody will ever use a function pointer for it ;-)

2

case ’*’ : result = Multiply(a, b); break;
case ’/’ : result = Divide (a, b); break;
}

cout << "switch: 2+5=" << result << endl; // display result
}

// solution with a function pointer - <pt2Func> is a function pointer and points to
// a function which takes two floats and returns a float. The function pointer
// "specifies" which operation shall be executed.
void Switch_With_Function_Pointer(float a, float b, float (*pt2Func)(float, float))
{
float result = pt2Func(a, b); // call using function pointer

cout << "switch replaced by function pointer: 2-5="; // display result
cout << result << endl;
}

// execute example code
void Replace_A_Switch()
{
cout << endl << "Executing function ’Replace_A_Switch’" << endl;

Switch(2, 5, /* ’+’ specifies function ’Plus’ to be executed */ ’+’);
Switch_With_Function_Pointer(2, 5, /* pointer to function ’Minus’ */ &Minus);
}

Important note: A function pointer always points to a function with a specific signature! Thus all functions,
you want to use with the same function pointer, must have the same parameters and return-type!

2 The Syntax of C and C++ Function Pointers
Regarding their syntax, there are two different types of function pointers: On the one hand there are pointers
to ordinary C functions or static C++ member functions, on the other hand there are pointers to non-static
C++ member functions. The basic difference is that all pointers to non-static member functions need a hidden
argument: The this-pointer to an instance of the class. Always keep in mind: These two types of function
pointers are incompatible with each other.

2.1 Define a Function Pointer
Since a function pointer is nothing else than a variable, it must be defined as usual. In the following example
we define two function pointers named pt2Function and pt2Member. They point to functions, which take one
float and two char and return an int. In the C++ example it is assumed, that the function, our pointer points
to, is a member function of TMyClass.

// 2.1 define a function pointer
int (*pt2Function) (float, char, char); // C
int (TMyClass::*pt2Member)(float, char, char); // C++

2.2 Calling Convention
Normally you don’t have to think about a function’s calling convention: The compiler assumes cdecl as
default if you don’t specify another convention. However if you want to know more, keep on reading ... The
calling convention tells the compiler things like how to pass the arguments or how to generate the name of a
function. Examples for other calling conventions are stdcall, pascal, fastcall. The calling convention belongs
to a functions signature: Thus functions and function pointers with different calling convention
are incompatible with each other! For Borland and Microsoft compilers you specify a specific calling
convention between the return type and the function’s or function pointer’s name. For the GNU GCC you use

3

the attribute keyword: Write the function deﬁnition followed by the keyword attribute and then state the
calling convention in double parentheses.3
// 2.2 define the calling convention
void __cdecl DoIt(float a, char b, char c); // Borland and Microsoft
void DoIt(float a, char b, char c) __attribute__((cdecl)); // GNU GCC

2.3 Assign an Address to a Function Pointer
It’s quite easy to assign the address of a function to a function pointer. You simply take the name of a suitable
and known function or member function. It’s optional to use the address operator & in front of the function’s
name. Note: You may have got to use the complete name of the member function including class-name and
scope-operator (::). Also you have got to ensure, that you are allowed to access the function right in scope
where your assignment stands.
// 2.3 assign an address to the function pointer

// C
int DoIt (float a, char b, char c){ printf("DoItn"); return a+b+c; }
int DoMore(float a, char b, char c){ printf("DoMoren"); return a-b+c; }

pt2Function = DoMore; // assignment
pt2Function = &DoIt; // alternative using address operator

// C++
class TMyClass
{
public:
int DoIt (float a, char b, char c){ cout << "TMyClass::DoIt" << endl; return a+b+c; };
int DoMore(float a, char b, char c){ cout << "TMyClass::DoMore" << endl; return a-b+c; };

/* more of TMyClass */
};
pt2Member = TMyClass::DoIt; // assignment
pt2Member = &TMyClass::DoMore; // alternative using address operator

2.4 Comparing Function Pointers
You can use the comparison-operator (==) to compare function pointers with each other or with functions. In
the following example it is checked, whether pt2Function and pt2Member actually contain the address of the
functions DoIt and TMyClass::DoMore. A text is shown in case of equality.
// 2.4 compare function pointers to functions

// C
if(pt2Function == &DoIt)
printf("pointer points to DoItn");

// C++
if(pt2Member == &TMyClass::DoMore)
cout << "pointer points to TMyClass::DoMore" << endl;

2.5 Calling a Function using a Function Pointer
In C you have two alternatives of how to call a function using a function pointer: You can just use the name
of the function pointer instead of the name of the function or you can explicitly de-reference it. In C++ it’s a
little bit tricky since you need to have an instance of a class to call one of their (non-static) member functions.
If the call takes place within another member function you can use the this-pointer.
3 If someone knows more: Let me know ;-) And if you want to know how function calls work under the hood you should take a

look at the chapter Subprograms in Paul Carter’s PC Assembly Tutorial (http://www.drpaulcarter.com/pcasm/).

4

// 2.5 calling a function using a function pointer
int result1 = pt2Function (12, ’a’, ’b’); // C short way
int result2 = (*pt2Function) (12, ’a’, ’b’); // C

TMyClass instance;
int result3 = (instance.*pt2Member)(12, ’a’, ’b’); // C++
int result4 = (*this.*pt2Member)(12, ’a’, ’b’); // C++ if this-pointer can be used

2.6 How to Pass a Function Pointer as an Argument ?
You can pass a function pointer as a function’s calling argument. You need this for example if you want to pass
a pointer to a callback function. The following code shows how to pass a pointer to a function which returns
an int and takes a float and two char:

//-----------------------------------------------------------------------------------------
// 2.6 How to Pass a Function Pointer

// <pt2Func> is a pointer to a function which returns an int and takes a float and two char
void PassPtr(int (*pt2Func)(float, char, char))
{
float result = pt2Func(12, ’a’, ’b’); // call using function pointer

cout << result << endl;
}

// execute example code - ’DoIt’ is a suitable function like defined above in 2.1-4
void Pass_A_Function_Pointer()
{
cout << endl << "Executing ’Pass_A_Function_Pointer’" << endl;
PassPtr(&DoIt);
}

2.7 How to Return a Function Pointer ?
It’s a little bit tricky but a function pointer can be a function’s return value. In the following example there
are two solutions of how to return a pointer to a function which is taking a float and returns two float. If you
want to return a pointer to a member function you have just got to change the definitions/declarations of all
function pointers.

//-----------------------------------------------------------------------------------------
// 2.7 How to Return a Function Pointer
// ’Plus’ and ’Minus’ are defined above in 2.1-4. They return a float and take two float

// direct solution
// function takes a char and returns a pointer to a function which is taking two
// floats and returns a float. <opCode> specifies which function to return
float (*GetPtr1(const char opCode))(float, float)
{
if(opCode == ’+’) return &Plus;
if(opCode == ’-’) return &Minus;
}

// solution using a typedef
// define a pointer to a function which is taking two floats and returns a float
typedef float(*pt2Func)(float, float);

5

// function takes a char and returns a function pointer which is defined as a
// type above. <opCode> specifies which function to return
pt2Func GetPtr2(const char opCode)
{
if(opCode == ’+’) return &Plus;
if(opCode == ’-’) return &Minus;
}

void Return_A_Function_Pointer()
{
cout << endl << "Executing ’Return_A_Function_Pointer’" << endl;

float (*pt2Function)(float, float); // define a function pointer

pt2Function=GetPtr1(’+’); // get function pointer from function ’GetPtr1’
cout << pt2Function(2, 4) << endl; // call function using the pointer

pt2Function=GetPtr2(’-’); // get function pointer from function ’GetPtr2’
cout << pt2Function(2, 4) << endl; // call function using the pointer
}

2.8 How to Use Arrays of Function Pointers ?
Operating with arrays of function pointer is very interesting. This oﬀers the possibility to select a function
using an index. The syntax appears diﬃcult, which frequently leads to confusion.

//-----------------------------------------------------------------------------------------
// 2.8 How to Use Arrays of C Function Pointers

// C
// type-definition: ’pt2Function’ now can be used as type
typedef int (*pt2Function)(float, char, char);

// illustrate how to work with an array of function pointers
void Array_Of_Function_Pointers()
{
printf("Executing ’Array_Of_Function_Pointers’n");

// <funcArr> is an array with 10 pointers to functions which return an int
// and take a float and two char
pt2Function funcArr[10];

// assign the function’s address - ’DoIt’ and ’DoMore’ are suitable functions
// like defined above in 2.1-4
funcArr[0] = &DoIt;
funcArr[1] = &DoMore;
/* more assignments */

// calling a function using an index to address the function pointer
printf("%dn", funcArr[1](12, ’a’, ’b’));
printf("%dn", funcArr[0](12, ’a’, ’b’));
}

6

// C++
// type-definition: ’pt2Member’ now can be used as type
typedef int (TMyClass::*pt2Member)(float, char, char);

// illustrate how to work with an array of member function pointers
void Array_Of_Member_Function_Pointers()
{
cout << endl << "Executing ’Array_Of_Member_Function_Pointers’" << endl;

// <funcArr> is an array with 10 pointers to member functions which return an
// int and take a float and two char
pt2Member funcArr[10];

// assign the function’s address - ’DoIt’ and ’DoMore’ are suitable member functions
// of class TMyClass like defined above in 2.1-4
funcArr[0] = &TMyClass::DoIt;
funcArr[1] = &TMyClass::DoMore;
/* more assignments */

// calling a function using an index to address the member function pointer
// note: an instance of TMyClass is needed to call the member functions
TMyClass instance;
cout << (instance.*funcArr[1])(12, ’a’, ’b’) << endl;
cout << (instance.*funcArr[0])(12, ’a’, ’b’) << endl;
}

3 How to Implement Callback Functions in C and C++
3.1 Introduction to the Concept of Callback Functions
Function Pointers provide the concept of callback functions. I’ll try to introduce the concept of callback functions
using the well known sort function qsort. This function sorts the items of a field according to a user-specific
ranking. The field can contain items of any type; it is passed to the sort function using a void-pointer. Also the
size of an item and the total number of items in the field has got to be passed. Now the question is: How can
the sort-function sort the items of the field without any information about the type of an item? The answer is
simple: The function receives the pointer to a comparison-function which takes void-pointers to two field-items,
evaluates their ranking and returns the result coded as an int. So every time the sort algorithm needs a decision
about the ranking of two items, it just calls the comparison-function via the function pointer.

3.2 How to Implement a Callback in C ?
To explain I just take the declaration of the function qsort which reads itself as follows4 :

void qsort(void* field, size_t nElements, size_t sizeOfAnElement,
int(_USERENTRY *cmpFunc)(const void *, const void*));

field points to the first element of the field which is to be sorted, nElements is the number of items in the field,
sizeOfAnElement the size of one item in bytes and cmpFunc is the pointer to the comparison function. This
comparison function takes two void-pointers and returns an int. The syntax, how you use a function pointer
as a parameter in a function-definition looks a little bit strange. Just review, how to define a function pointer
and you’ll see, it’s exactly the same. A callback is done just like a normal function call would be done: You
just use the name of the function pointer instead of a function name. This is shown below. Note: All calling
arguments despite the function pointer were omitted to focus on the relevant things.
4 Taken from the Borland Compiler C++ 5.02 (BC5.02)

7

void qsort( ... , int(_USERENTRY *cmpFunc)(const void*, const void*))
{
/* sort algorithm - note: item1 and item2 are void-pointers */

int bigger=cmpFunc(item1, item2); // make callback

/* use the result */
}

3.3 Example Code of the Usage of qsort
//-----------------------------------------------------------------------------------------
// 3.3 How to make a callback in C by the means of the sort function qsort

#include <stdlib.h> // due to: qsort
#include <time.h> // randomize
#include <stdio.h> // printf

// comparison-function for the sort-algorithm
// two items are taken by void-pointer, converted and compared
int CmpFunc(const void* _a, const void* _b)
{
// you’ve got to explicitly cast to the correct type
const float* a = (const float*) _a;
const float* b = (const float*) _b;

if(*a > *b) return 1; // first item is bigger than the second one -> return 1
else
if(*a == *b) return 0; // equality -> return 0
else return -1; // second item is bigger than the first one -> return -1
}

// example for the use of qsort()
void QSortExample()
{
float field[100];

::randomize(); // initialize random-number-generator
for(int c=0;c<100;c++) // randomize all elements of the field
field[c]=random(99);

// sort using qsort()
qsort((void*) field, /*number of items*/ 100, /*size of an item*/ sizeof(field[0]),
/*comparison-function*/ CmpFunc);

// display first ten elements of the sorted field
printf("The first ten elements of the sorted field are ...n");
for(int c=0;c<10;c++)
printf("element #%d contains %.0fn", c+1, field[c]);
printf("n");
}

3.4 How to Implement a Callback to a static C++ Member Function ?
This is the same as you implement callbacks to C functions. Static member functions do not need an object
to be invoked on and thus have the same signature as a C function with the same calling convention, calling
arguments and return type.

8

3.5 How to Implement a Callback to a non-static C++ Member Function ?
Pointers to non-static members are different to ordinary C function pointers since they need the this-pointer
of a class object to be passed. Thus ordinary function pointers and non-static member functions have different
and incompatible signatures! If you just want to callback to a member of a specific class you just change your
code from an ordinary function pointer to a pointer to a member function. But what can you do, if you want
to callback to a non-static member of an arbitrary class? It’s a little bit difficult. You need to write a
static member function as a wrapper. A static member function has the same signature as a C function! Then
you cast the pointer to the object on which you want to invoke the member function to void* and pass it to
the wrapper as an additional argument or via a global variable.5 Of course you’ve also got to pass the
calling arguments for the member function. The wrapper casts the void-pointer to a pointer to an instance of
the correct class and calls the member function. Below you find two examples:

Example A: Pointer to a class instance passed as an additional argument The function DoItA does
something with objects of the class TClassA which implies a callback. Therefore a pointer to an object of class
TClassA and a pointer to the static wrapper function TClassA::Wrapper To Call Display are passed to DoItA.
This wrapper is the callback-function. You can write arbitrary other classes like TClassA and use them with
DoItA as long as these other classes provide the necessary functions. Note: This solution may be useful if you
design the callback interface yourself. It is much better than the second solution which uses a global variable.

//-----------------------------------------------------------------------------------------
// 3.5 Example A: Callback to member function using an additional argument
// Task: The function ’DoItA’ makes something which implies a callback to
// the member function ’Display’. Therefore the wrapper function
// ’Wrapper_To_Call_Display is used.


class TClassA
{
public:

void Display(const char* text) { cout << text << endl; };
static void Wrapper_To_Call_Display(void* pt2Object, char* text);

/* more of TClassA */
};

// static wrapper function to be able to callback the member function Display()
void TClassA::Wrapper_To_Call_Display(void* pt2Object, char* string)
{
// explicitly cast to a pointer to TClassA
TClassA* mySelf = (TClassA*) pt2Object;

// call member
mySelf->Display(string);
}

// function does something which implies a callback
// note: of course this function can also be a member function
void DoItA(void* pt2Object, void (*pt2Function)(void* pt2Object, char* text))
{
/* do something */

pt2Function(pt2Object, "hi, i’m calling back using a argument ;-)"); // make callback
}

5 If you use a global variable it is very important that you make sure that it will always point to the correct object!

9

void Callback_Using_Argument()
{
// 1. instantiate object of TClassA
TClassA objA;

// 2. call ’DoItA’ for <objA>
DoItA((void*) &objA, TClassA::Wrapper_To_Call_Display);
}

Example B: Pointer to a class instance is stored in a global variable The function DoItB does
something with objects of the class TClassB which implies a callback. A pointer to the static wrapper function
TClassB::Wrapper To Call Display is passed to DoItB. This wrapper is the callback-function. The wrapper
uses the global variable void* pt2Object and explicitly casts it to an instance of TClassB. It is very important,
that you always initialize the global variable to point to the correct class instance. You can write arbitrary other
classes like TClassB and use them with DoItB as long as these other classes provide the necessary functions.
Note: This solution may be useful if you have an existing callback interface which cannot be changed. It is
not a good solution because the use of a global variable is very dangerous and could cause serious errors.

//-----------------------------------------------------------------------------------------
// 3.5 Example B: Callback to member function using a global variable
// Task: The function ’DoItB’ makes something which implies a callback to
// the member function ’Display’. Therefore the wrapper function
// ’Wrapper_To_Call_Display is used.


void* pt2Object; // global variable which points to an arbitrary object

class TClassB
{
public:

static void Wrapper_To_Call_Display(char* text);

/* more of TClassB */
};

// static wrapper function to be able to callback the member function Display()
void TClassB::Wrapper_To_Call_Display(char* string)
{
// explicitly cast global variable <pt2Object> to a pointer to TClassB
// warning: <pt2Object> MUST point to an appropriate object!
TClassB* mySelf = (TClassB*) pt2Object;

// call member
mySelf->Display(string);
}

// function does something which implies a callback
// note: of course this function can also be a member function
void DoItB(void (*pt2Function)(char* text))
{
/* do something */

pt2Function("hi, i’m calling back using a global ;-)"); // make callback
}

10

void Callback_Using_Global()
{
// 1. instantiate object of TClassB
TClassB objB;

// 2. assign global variable which is used in the static wrapper function
// important: never forget to do this!!
pt2Object = (void*) &objB;

// 3. call ’DoItB’ for <objB>
DoItB(TClassB::Wrapper_To_Call_Display);
}

4 Functors to encapsulate C and C++ Function Pointers
4.1 What are Functors ?
Functors are functions with a state. In C++ you can realize them as a class with one or more private members
to store the state and with an overloaded operator6 () to execute the function. Functors can encapsulate C and
C++ function pointers employing the concepts templates and polymorphism. You can build up a list of pointers
to member functions of arbitrary classes and call them all through the same interface without bothering about
their class or the need of a pointer to an instance. All the functions just have got to have the same return-
type and calling parameters. Sometimes Functors are also known as Closures. You can also use Functors to
implement callbacks.

4.2 How to Implement Functors ?
First you need a base class TFunctor which provides a virtual function named Call or a virtually overloaded
operator () with which you will be able to call the member function. It’s up to you if you prefer the overloaded
operator or a function like Call. From the base class you derive a template class TSpeciﬁcFunctor which
is initialized with a pointer to an object and a pointer to a member function in its constructor. The derived
class overrides the function Call and/or the operator () of the base class: In the overrided versions
it calls the member function using the stored pointers to the object and to the member function.

//-----------------------------------------------------------------------------------------
// 4.2 How to Implement Functors

// abstract base class
class TFunctor
{
public:

// two possible functions to call member function. virtual cause derived
// classes will use a pointer to an object and a pointer to a member function
// to make the function call
virtual void operator()(const char* string)=0; // call using operator
virtual void Call(const char* string)=0; // call using function
};

// derived template class
template <class TClass> class TSpecificFunctor : public TFunctor
{
private:
void (TClass::*fpt)(const char*); // pointer to member function
TClass* pt2Object; // pointer to object
6 If you prefer you can also use a function called Execute or something like that.

11

public:

// constructor - takes pointer to an object and pointer to a member and stores
// them in two private variables
TSpecificFunctor(TClass* _pt2Object, void(TClass::*_fpt)(const char*))
{ pt2Object = _pt2Object; fpt=_fpt; };

// override operator "()"
virtual void operator()(const char* string)
{ (*pt2Object.*fpt)(string);}; // execute member function

// override function "Call"
virtual void Call(const char* string)
{ (*pt2Object.*fpt)(string);}; // execute member function
};

4.3 Example of How to Use Functors
In the following example we have two dummy classes which provide a function called Display which returns
nothing (void) and needs a string (const char*) to be passed. We create an array with two pointers to TFunctor
and initialize the array entries with two pointers to TSpeciﬁcFunctor which encapsulate the pointer to an
object and the pointer to a member of TClassA respectively TClassB. Then we use the functor-array to call
the respective member functions. No pointer to an object is needed to make the function calls and
you do not have to bother about the classes anymore!
//-----------------------------------------------------------------------------------------
// 4.3 Example of How to Use Functors

// dummy class A
class TClassA{
public:
TClassA(){};
/* more of TClassA */
};

// dummy class B
class TClassB{
public:
TClassB(){};
/* more of TClassB */
};

// main program
int main(int argc, char* argv[])
{
// 1. instantiate objects of TClassA and TClassB
TClassA objA;
TClassB objB;

// 2. instantiate TSpecificFunctor objects ...
// a ) functor which encapsulates pointer to object and to member of TClassA
TSpecificFunctor<TClassA> specFuncA(&objA, TClassA::Display);

// b) functor which encapsulates pointer to object and to member of TClassB
TSpecificFunctor<TClassB> specFuncB(&objB, &TClassB::Display);

// 3. create array with pointers to TFunctor, the base class and ...

12

TFunctor** vTable = new TFunctor*[2];

// ... assign functor addresses to the function pointer array
vTable[0] = &specFuncA;
vTable[1] = &specFuncB;

// 4. use array to call member functions without the need of an object
vTable[0]->Call("TClassA::Display called!"); // via function "Call"
(*vTable[1]) ("TClassB::Display called!"); // via operator "()"

// 5. release
delete[] vTable;

cout << endl << "Hit Enter to terminate!" << endl;
cin.get();
return 0;
}

13

The Function Pointer Tutorials

More Related Content

Similar to The Function Pointer Tutorials

More from Nont Banditwong

Recently uploaded

The Function Pointer Tutorials
