HTML5 game dev with three.js - HexGL

• Thibaut Despoulain (@bkcore – bkcore.com)

• 22 year-old student in Computer Engineering

• University of Technology of Belfort-Montbéliard (France)

• Web dev and 3D enthousiast

• The guy behind the HexGL project

• Fast-paced, futuristic racing game

• Inspired by the F-Zero and Wipeout series

• HTML5, JavaScript, WebGL (via Three.js)

• Less than 2 months

• Just me.

• JavaScript API

• OpenGL ES 2.0

• Chrome, FireFox, (Opera, Safari)

• <Canvas> (HTML5)

• Rendering engine
• Maintained by Ricardo Cabello (MrDoob) and Altered Qualia
• R50/stable

• + : Active community, stable, updated frequently

• - : Documentation

• First « real » game

• 2 months to learn and code

• Little to no modeling and texturing skills

• Physics? Controls? Gameplay?

• Last time I could have 2 months free

• Visibility to get an internship

• Huge learning opportunity

• Explore Three.js for good

• Third-party physics engine (rejected)
– Slow learning curve

– Not really meant for racing games

• Ray casting (rejected)
– Heavy perfomance-wise

– Needs Octree-like structure

– > too much time to learn and implement

• Home-made 2D approximation
– Little to no learning curve

– Easy to implement with 2D maps

– Pretty fast

– > But with some limitations

• Home-made 2D approximation
– No track overlap

– Limited track twist and gradient

– Accuracy depends on map resolution

– > Enough for what I had in mind

• No pixel getter on JS Image object/tag

• Canvas2D to the rescue

Load data Draw it on a Get canvas

Drawing

Getting
Loading

texture with JS Canvas using pixels using
Image object 2D context getImageData()

• ImageData (BKcore package)
– Github.com/Bkcore/bkcore-js

var a = new bkcore.ImageData(path, callback);
//…
a.getPixel(x, y);
a.getPixelBilinear(xf, yf);
// -> {r, g, b, a};

Game loop:
Convert world position to pixel indexes
Get current pixel intensity (red)
If pixel is not white:
Collision
Test pixels relatively (front, left, right)
:end

Front

Left Right

Track Void

Front

Front
Current
Gradient
Left Right Left

Right
Height map Tilt

Model
.OBJ Python Three.js
Materials converter JSON model
.MTL

$ python convert_obj_three.py -i mesh.obj -o mesh.js

var scene = new THREE.Scene();
var loader = new THREE.JSONLoader();

var createMesh = function(geometry)
{
var mesh = new THREE.Mesh(geometry, new THREE.MeshFaceMaterial());
mesh.position.set(0, 0, 0);
mesh.scale.set(3, 3, 3);
scene.add(mesh);
};

loader.load("mesh.js", createMesh);

var renderer = new THREE.WebGLRenderer({
antialias: false,
clearColor: 0x000000
});

renderer.autoClear = false;
renderer.sortObjects = false;
renderer.setSize(width, height);
document.body.appendChild(renderer.domElement);

renderer.gammaInput = true;

renderer.gammaOutput = true;

renderer.shadowMapEnabled = true;

renderer.shadowMapSoft = true;

• Blinn-phong
– Diffuse + Specular + Normal + Environment maps

• THREE.ShaderLib.normal
– > Per vertex point lights

• Custom shader with per-pixel point lights for the road
– > Booster light

var boosterSprite = new THREE.Sprite(
{
map: spriteTexture,
blending: THREE.AdditiveBlending,
useScreenCoordinates: false,
color: 0xffffff
});

boosterSprite.mergeWith3D = false;
boosterMesh.add(boosterSprite);

var material = new THREE.ParticleBasicMaterial({
color: 0xffffff,
map: THREE.ImageUtils.loadTexture(“tex.png”),
size: 4,
blending: THREE.AdditiveBlending,
depthTest: false,
transparent: true,
vertexColors: true,
sizeAttenuation: true
});

var pool = [];
var geometry = new THREE.Geometry();
geometry.dynamic = true;

for(var i = 0; i < 1000; ++i)
{
var p = new bkcore.Particle();
pool.push(p);
geometry.vertices.push(p.position);
geometry.colors.push(p.color);
}

bkcore.Particle = function()
{
this.position = new THREE.Vector3();
this.velocity = new THREE.Vector3();
this.force = new THREE.Vector3();
this.color = new THREE.Color(0x000000);
this.basecolor = new THREE.Color(0x000000);
this.life = 0.0;
this.available = true;
}

var system = new THREE.ParticleSystem(
geometry,
material
);
system.sort = false;

system.position.set(x, y, z);
system.rotation.set(a, b, c);

scene.add(system);

// Particle physics
var p = pool[i];
p.position.addSelf(p.velocity);
//…
geometry.verticesNeedUpdate = true;
geometry.colorsNeedUpdate = true;

• Particles (BKcore package)
– Github.com/BKcore/Three-extensions

var clouds = new bkcore.Particles({
opacity: 0.8,
tint: 0xffffff, color: 0x666666, color2: 0xa4f1ff,
texture: THREE.ImageUtils.loadTexture(“cloud.png”),
blending: THREE.NormalBlending,
size: 6, life: 60, max: 500,
spawn: new THREE.Vector3(3, 3, 0),
spawnRadius: new THREE.Vector3(1, 1, 2),
velocity: new THREE.Vector3(0, 0, 4),
randomness: new THREE.Vector3(5, 5, 1)
});

scene.add(clouds);

// Game loop
clouds.emit(10);
clouds.update(dt);

• Built-in support for off-screen passes

• Already has some pre-made post effects
– Bloom

– FXAA

• Easy to use and Extend

• Custom shaders

var renderTargetParameters = {
minFilter: THREE.LinearFilter,
magFilter: THREE.LinearFilter,
format: THREE.RGBFormat,
stencilBuffer: false
};
var renderTarget = new THREE.WebGLRenderTarget(
width, height,
renderTargetParameters
);

var composer = new THREE.EffectComposer(
renderer,
renderTarget
);

composer.addPass( … );

composer.render();

• Generic passes
– RenderPass
– ShaderPass
– SavePass
– MaskPass

• Pre-made passes
– BloomPass
– FilmPass
– Etc.

var renderModel = new THREE.RenderPass(
scene,
camera
);

renderModel.clear = false;

composer.addPass(renderModel);

var effectBloom = new THREE.BloomPass(
0.8, // Strengh
25, // Kernel size
4, // Sigma
256 // Resolution
);

composer.addPass(effectBloom);

var hexvignette: {
uniforms: {
tDiffuse: { type: "t", value: 0, texture: null },
tHex: { type: "t", value: 1, texture: null},
size: { type: "f", value: 512.0},
color: { type: "c", value: new THREE.Color(0x458ab1) }
},
fragmentShader: [
"uniform float size;",
"uniform vec3 color;",
"uniform sampler2D tDiffuse;",
"uniform sampler2D tHex;",

"varying vec2 vUv;",

"void main() { ... }"

].join("n")
};

var effectHex = new THREE.ShaderPass(hexvignette);

effectHex.uniforms['size'].value = 512.0;
effectHex.uniforms['tHex'].texture = hexTexture;

composer.addPass(effectHex);

//…
effectHex.renderToScreen = true;
