  The Trusted Computing Architecture
• 2.
  Index • Introduction toTrusted Computing • TPM Provisioning • Exact Mechanics of TPM
• 3.
  Introduction to TrustedComputing • Trusted computing (TC) is the concept that technologies have built-in processes to revolve basic security problems and user challenges [1]. • It is also a term used by a trade group called the Trusted Computing Group (TCG) that helps to set standards for devices and technologies.
• 4.
  TPM Provisioning • Componentsof TMP Chip are shown in Figure 1 [2]. • RSA: 1024, 2048 bit modulus • SHA-1: Outputs 20 byte digest Figure 1: TPM Components
• 5.
  Non-Volatile Storage 1. EndorsementKey (EK) – 2048-bit RSA • Created at manufacturing time. Cannot be changed. • Used for attestation 2. Storage Key (SRK) – 2048-bit RSA • Used for implementing encrypted storage • Created after running – TPM_TakeOwnership (OwnerPassword, …) • Can be cleared later with TPM_ForceClear from BIOS 3. Storage Key (SRK) – 160 bits and persistent flags Private EK, SRK and OwnerPwd never leave the TPM
• 6.
  PCR – PlatformConfiguration Registers • Lots of PCR registers on chip (At least 16) • PCRs are initialized to default value (e.g. 0) at boot time • After boot, PCRs contain hash chain of booted software • Collision resistance of SHA1 ensures commitment • Embedding PCR values in blob ensures that only certain applications can decrypt the data
• 7.
  Exact Mechanics ofTPM • TPM accepts a value from outside software and a hash of the protocols that produced the value [3]. • This allows the platform to use whatever they want to set the value from secure time to the local PC clock. • TPM just keeps the audit digest and no other information.
• 8.
  Exact Mechanics ofTPM • Startup Mode – Startup transitions the TPM from the initialization state to an operational state. • The transition includes information from the platform to inform the TPM of the platform operating state. • TPM_Startup has three options: Clear, State and Deactivated.
• 9.
  Exact Mechanics ofTPM • Operational Mode – After the TPM completes both TPM_Startup and self-tests, the TPM is ready for operation. • There are three discrete states, enabled or disabled, active or inactive and owned or un-owned. • These three states when combined form eight operational modes.
• 10.
  Exact Mechanics ofTPM • Clearing the TPM – Clearing the TPM is the process of returning the TPM to factory defaults. • It is possible the platform owner will change when in this state. • The commands to clear a TPM require either TPM Owner authentication or the assertion of physical presence.
• 11.
  References 1. Maene, P.,Götzfried, J., De Clercq, R., Müller, T., Freiling, F., & Verbauwhede, I. (2018). Hardware-based trusted computing architectures for isolation and attestation. IEEE Transactions on Computers, 67(3), 361-374. 2. https://crypto.stanford.edu/cs155old/cs155-spring11/lectures/08-TCG.pdf 3. https://trustedcomputinggroup.org/resource/tpm-main-specification/
