Lecture 1 sorting insertion & shell sort
This document discusses several sorting algorithms including insertion sort, shell sort, heap sort, quick sort, merge sort, bucket sort, and radix sort. It provides details on insertion sort and shell sort, including their algorithms, examples, and exercises to implement them in C code. Insertion sort works by dividing a list into sorted and unsorted parts, moving elements in the unsorted part into the sorted part in the correct position. Shell sort, an improved version of insertion sort, works similarly but divides the list into segments defined by an increment value.
More Related Content
Similar to Lecture 1 sorting insertion & shell sort
Lecture 1 sorting insertion & shell sort
- 1. Insertion Sort &Shell Sort
- 2. Sorting Is a processthrough which the data are arranged according to their values. Why sorting?
- 3. Sorting Algorithms Insertion sort Shellsort Heap sort Quick sort Merge sort Bucket sort Radix sort
- 4. Insertion sort The listis divided in to 2 parts: sorted & unsorted In each pass the 1st element of the unsorted sub-list is transferred to the sorted sub-list by inserting it at the appropriate place. If the list contains ‘n’ elements then there will be ‘n- 1’ passes.
- 5.
- 6. Algorithm Insertion sort: Step 1:Repeat Step 2 to 5 for k=1 to N Setp 2: Set Temp=arr[k] Setp 3: Set j=k Setp 4: Repeat while j>0 && temp<=arr[j-1] Step 4.1: Set arr[j]=arr[j-1] step 4.2: Set j=j-1 Step 5:Set arr[j]=Temp Step 6: Exit
- 7. Shell Sort Created byDonald L. Shell Improved version of the insertion sort In this a list of N element is divided into K segments, where K is known as the increment. Each pass through the data starts with the 1st element in the array and progresses through the array, comparing adjacent elements in each segment.
- 8.
- 9.
- 10.
- 11. Algorithm shellsort( input_type a[], unsigned int n ) { unsigned int i, j, increment; input_type tmp; 1. for( increment = n/2; increment > 0; increment /= 2 ) 2. for( i = increment; i<n; i++ ) { 3. tmp = a[i]; 4. for( j = i; j >= increment; j -= increment ) 5. if( tmp < a[j-increment] ) 6. a[j] = a[j-increment]; Else 7. break; 8. a[j] = tmp; } }
- 12. Exercise 1. Write aC-program to implement Insertion Sort. 2. Write a C-program to implement Shell Sort. 3. Perform Insertion sort with the help of the algorithm and show 2-passes for the following sequence. 20,40,30,10,60 4. Perform Shell sort with the help of the algorithm and show 2-Increments for the following sequence. 30, 40, 20, 15, 25, 10, 35, 4
- 13. Reference Books 1. DataStructures & Algorithm Analysis in C Mark Allen Weiss 2. Data Structures –A Pseudocode Approach with C Gilberg & Forouzan
